2 Everything you will need for maintenance HS Preventive Maintenance
01/2006 US Edition
10
2.2 Consumables
Have the following consumables to hand before you start the maintenance: 2
2.3 Wearing parts
Have the following wearing parts to hand before you start the maintenance: 2
Consumables From item number
Protective latex gloves 00372972-01
Soft, lint-free cloths
Cottonwool buds, lint-free 00352931-02
Microtips medium precision applicators (cottonwool buds) 03020860S01
SIPLACE cleaning tissue 00315253-02
Lens cloth
Ethyl alcohol
ISOFLEX TOPAS, NCA 52 00328369-01 1 kg can,
00330850-01 50g tube
UNISILKON L250L 00310259S01
WD40, 400 ml 00325833-01
Z axis oil dispenser with Structovis GHD (HS-50) 00367071-01
MULTEMP PS No. 2 grease gun (HS-60) (replaced by oil
dispenser)
03011577S01
Fin Grease spray grease (aerosol) 03020782-01
Wearing parts From item number
Filter mat 230x360 for air filter box 00315209-01
Modulair 112 G 1/2 inch filter
new version
old version (for 00329906-01 only)
00349311S01
00336902S01
Filter insert, 5 microm. for series 112 00355386-01
Silencer for the Collect&Place head DLM1 (HS-50) 00359582S01
Silencer for the Collect&Place head DLM2 (HS-60) 03003134S01
O-ring for valve plunger 00345127-01
Set of valve plungers 00351498-03
Set of cleaned ceramic nozzles or new nozzles
HS Preventive Maintenance 2 Everything you will need for maintenance
01/2006 US Edition
11
2.4 Spare parts
Have the following spare parts to hand before you start the maintenance: 2
Damping cylinder for protective cover 00334359-01
Grease nipple (1 pack = 8x) 00366104-01
Z axis toothed belt 00334936S01
Distributor 00319827S02
PAS-LX-12 distributor plate, complete 00368211S01
O-ring, turning station 00320043S01
Toothed belt, turning station 00320041S01
Suction plate for ball catch, complete (10 x) 00354244S01
O-ring for distributor 8*1 NBR 70 B 00201179S01
Star brake for star, complete 03001653S01
O-ring, Venturi nozzle
O-ring, 10*1.5 NBR 70 B
O-ring, 14*1.5 NBR 70 B
O-ring, 8*1 Viton 75
O-ring, 10*1 Viton 75
00320047S01
00320048S01
00350661S01
00350662S01
Vacuum nozzle, 1.5 dia.
Vacuum nozzle, 1.0 dia.
00319420S03
00319423S02
Wearing parts From item number
Spare parts From item number
Air filter box (option) 00119016-01
S50 pneumatic system 00329906-03
Sensitive switch for head crash guard 00338005-01
Set of sleeves (type 12) 00116143S01
Set of sleeves (type 6) 00116114S01
Individual sleeve (type 12) 00350588S02
Individual sleeve (type 6) 00352957S02
Vacuum generator, complete, DLM 1 (HS-50 only) 00335989S02
Vacuum generator, complete, DLM 2 (HS-60 only) 03003236S01
2 Everything you will need for maintenance HS Preventive Maintenance
01/2006 US Edition
12
2.5 Important points to note when carrying out main-
tenance work
The maintenance intervals given for inspecting and replacing the filter elements only apply to the
specified compressed air quality (compressed air specification). If other qualities are used, the
maintenance intervals should be shortened accordingly. 2
CAUTION
NEVER use compressed air to clean inside the placement machine’s modules. 2
Enter the completed maintenance work in the maintenance schedule. We recommend that you
carry out the jobs in the order given in the maintenance schedule. 2
