iii TR7600 SIII Series User Guide – Installation

Figure 40: The Connection of Repair Station ................................................................. 21

Figure 41: Loader Socket Position .................................................................................. 22

Figure 42: Loader and Unloader Socket Position ........................................................... 22

Figure 43: Loader and Unloader Cable .......................................................................... 23

Figure 44: Unloader Socket ............................................................................................ 23

Figure 45: Operating & Storage Environment for TR7600 SIII ...................................... 24

Figure 46: Plug Type ....................................................................................................... 25

Figure 47: Phase Terminals ............................................................................................ 26

Figure 48: TRI 3-phase Cable Wiring ............................................................................. 26

Figure 49: No Fuse Power Switch .................................................................................. 27

Figure 50: Turn the Power Switch Clockwise to Turn Power On ................................... 27

Figure 51: Change the Plug Type ................................................................................... 28

Test Research, Inc.

1 TR7600 SIII Series User Guide – Installation

1 INTRODUCTION

This manual can be applied to TR7600 SIII.

1.1 Objectives

After you finish reading this manual, you should be able to:

 Understand requirements for the system installation.

 Prepare the system installation.

 Finish the system installation.

1.2 Overview

The whole process of installation includes:

1) System Delivery

2) Container Unpacking

3) Check Accessories

4) Uninstall Mounting Brackets

5) Install X-ray Tube

6) Install Three Color-Light Tower

7) Install Air Supply Cable

8) Install Monitor

9) Input/Output Signal Port (SMEMA)

10) Power Installation

11) Tube Warm Up

12) X-ray Radiation Measurement
