5.3 "TEACHING" Window (Submenu)

*3 "Information" Group Box

Displayed is the information on the operating time and current step.

*4 "Control Sw" Group Box

When the [ENABLE] button on the operation panel is pressed in 2

seconds after one of the buttons in the "Operation" group box (*1)

and the [ON] button (entitled "MOVE"), the selected action takes

place.

*5 [Return] Button

When this button is pressed, the previous sheet (the "Tray Teach

Pick-Up Pos. [Comp. Center Pos.]", the "Tray Teach Ecc. Pick-Up

Pos. [Pickup Loc. Adj]", or the "Tray Matrix Pitch XY-Side Length"

sheet) appears.
