1.8 Lists of Consumables and Important Servicing
Parts
Listed below are the parts that may be consumed within 1 year.
Contact our marketing department or sales agency whenever you
need to purchase some of these parts.
(a) The values in the "Recommended Q’ty/Year" column are
for your reference.
(b) Refer to "1. Periodic Maintenance" in "Section 4" for the
replacement procedures of these parts.
(1) Mechanical Parts for Elevator
Table D5-1
Product Name Part No. Part Name
Standard/
Q’ty
Remarks
Material
AC Servomotor 630 096 0778 MOTOR, SGMAH-04 1 - ER-2 002
AC-SERVO AAA2B
(2) Electrical Parts for Elevator
Table D5-2
Product Name Part No. Part Name
Standard/
Q’ty
Remarks
Material
Capacitor 630 089 2079 SENSOR, EX-23 1 - ER-7 037
PELEC
Capacitor 630 089 2086 SENSOR, OS-EX20E- 1 - ER-7 038
PELEC (SLIT) 05X3
Photosensor 630 000 0252 SENSOR, EE-SX671 4 - ER-7 046
1.8 Lists of Consumables and Important Servicing Parts
0311-002 4-15-1 AHI01EGP
Recom-
mended
Q’ty/Year
Exploded
View No.
(Reference)
Recom-
mended
Q’ty/Year
Exploded
View No.
(Reference)
Note
(3) Mechanical Parts for Traverse
Table D5-3
Product Name Part No. Part Name
Standard/
Q’ty
Remarks
Material
AC Servomotor 630 105 1031 MOTOR, HC-PQ23-U 1 - TR-5 022
AC-SERVO E
(4) Electrical Parts for Traverse
Table D5-4
Product Name Part No. Part Name
Standard/
Q’ty
Remarks
Material
Capacitor 630 096 4486 SENSOR, EX-13EB 1 - TR-4 316
PELEC
Capacitor 630 089 2079 SENSOR, EX-23 3 - TR-4 317
PELEC
Photosensor 630 000 0252 SENSOR, EE-SX671 1 - TR-4 318
Photosensor 630 000 0245 SENSOR, EE-SX670 2 - TR-4 922
Capacitor 630 089 2086 SENSOR, OS-EX20E- 3 - TR-4 923
PELEC (SLIT) 05X3
0311-002 4-15-2 AHI01EGP
1.8 Lists of Consumables and Important Servicing Parts
Recom-
mended
Q’ty/Year
Exploded
View No.
(Reference)
Recom-
mended
Q’ty/Year
Exploded
View No.
(Reference)
2. Troubleshooting
2.1 Scope
2.1.1 Troubleshooting
Refer to "1.1 Troubleshooting" in "Section 2" (the instruction manual
(Vol. 4: Maintenance and Troubleshooting) of the main machine) for
details.
2.1.2 "CHECK" Windows
Refer to "1.2.1 "CHECK" Windows" in "Section 2" (the instruction
manual (Vol. 4: Maintenance and Troubleshooting) of the main ma-
chine) for details.
2.1.3 "CHECK" List
Refer to "1.2.2 List of Check Messages" in "Section 2" (the instruction
manual (Vol. 4: Maintenance and Troubleshooting) of the main ma-
chine) for details.
2.1.4 "ERROR" Windows
Refer to "1.4 "ERROR" Windows" in "Section 2" (the instruction
manual (Vol. 4: Maintenance and Troubleshooting) of the main ma-
chine) for details.
