2. T roubleshooting 2. 1 Scope 2.1.1 T roubleshooting Refer to "1.1 T roubleshooting" in "Section 2" (the instruction manual (V ol. 4: Maintenance and T roubleshooting) of the main machine) for detail…
(3) Mechanical Parts for Traverse
Table D5-3
Product Name Part No. Part Name
Standard/
Q’ty
Remarks
Material
AC Servomotor 630 105 1031 MOTOR, HC-PQ23-U 1 - TR-5 022
AC-SERVO E
(4) Electrical Parts for Traverse
Table D5-4
Product Name Part No. Part Name
Standard/
Q’ty
Remarks
Material
Capacitor 630 096 4486 SENSOR, EX-13EB 1 - TR-4 316
PELEC
Capacitor 630 089 2079 SENSOR, EX-23 3 - TR-4 317
PELEC
Photosensor 630 000 0252 SENSOR, EE-SX671 1 - TR-4 318
Photosensor 630 000 0245 SENSOR, EE-SX670 2 - TR-4 922
Capacitor 630 089 2086 SENSOR, OS-EX20E- 3 - TR-4 923
PELEC (SLIT) 05X3
0311-002 4-15-2 AHI01EGP
1.8 Lists of Consumables and Important Servicing Parts
Recom-
mended
Q’ty/Year
Exploded
View No.
(Reference)
Recom-
mended
Q’ty/Year
Exploded
View No.
(Reference)
2. Troubleshooting
2.1 Scope
2.1.1 Troubleshooting
Refer to "1.1 Troubleshooting" in "Section 2" (the instruction manual
(Vol. 4: Maintenance and Troubleshooting) of the main machine) for
details.
2.1.2 "CHECK" Windows
Refer to "1.2.1 "CHECK" Windows" in "Section 2" (the instruction
manual (Vol. 4: Maintenance and Troubleshooting) of the main ma-
chine) for details.
2.1.3 "CHECK" List
Refer to "1.2.2 List of Check Messages" in "Section 2" (the instruction
manual (Vol. 4: Maintenance and Troubleshooting) of the main ma-
chine) for details.
2.1.4 "ERROR" Windows
Refer to "1.4 "ERROR" Windows" in "Section 2" (the instruction
manual (Vol. 4: Maintenance and Troubleshooting) of the main ma-
chine) for details.
2. Troubleshooting
0311-003 4-16 AHI01EGP
2.2 Easy Troubleshooting
This session describes the countermeasures against easy problems
to be taken by the operator of the machine.
When the operator cannot solve a problem, he/she should get in
contact with the supervisor (a person in charge of machine manage-
ment).
2.2.1 Impossible Power Operation of Multi-Layer Tray Feeder
Table D6
Symptom The elevator axis cannot be powered.
Cause (Cause 1) The main machine is not powered.
(Cause 2) The connector is disconnected.
(Cause 3) The safety door is not closed.
Remedy (Remedy 1) Power the main machine.
Refer to "2.1 Power Operation Impossible" in "Section 2" (the
instruction manual (Vol. 4: Maintenance and Troubleshooting) of
the main machine) for details.
(Remedy 2) Confirm that the connector is connected.
(Remedy 3) Close the safety door.
2.2.2 Countermeasures against Pick-Up Errors
Table D7
Symptom The component pick-up rate has deteriorated.
Cause (Cause 1) The vacuum pressure for component picks is not proper.
(Cause 2) The vacuum nozzle is not proper.
(Cause 3) The component pick-up position is not normal.
(Cause 4) There is a problem in transition of the pallet.
(Cause 5) The tray is not fixed normally.
(Cause 6) The pallet is warped.
(Cause 7) The anti-warpage plate for the pallet on the traverses is worn out.
Remedy (Remedy 1) Check the vacuum pumps and tubes.
(Remedy 2) Use a proper vacuum nozzle for the component.
(Remedy 3) Confirm that correct parameters are set as offsets for the
traverse axis, tray offsets in the pallet, tray matrix dimensions,
and the height data for tray components.
(Remedy 4) Check the elevator offset.
(Remedy 5) Fix the tray normally.
(Remedy 6) Check the flatness of the pallet and how the rails on both sides
are worn out.
(Remedy 7) Place the pallet on the chute and check the clearance.
2.2 Easy Troubleshooting
