Error ID Item Description
120201 TV #2 Axis Timing
120301 TV #2 Axis Data
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
120401 TV #2 Axis Limit
120402 TV #2 Axis Limit
(Cause 1) The X1 axis might have overrun due to generation of noises, overcurrent, etc.
The sensor may be defective.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
120601 TV #2 Axis Interlock Driver Alarm
120602 TV #2 Axis Interlock Pick-Up Error Detection (Upper)
120603 TV #2 Axis Interlock Pick-Up Error Detection (Lower)
120604 TV #2 Axis Interlock Pass-line Interlock
120605 TV #2 Axis Interlock
120606 TV #2 Axis Interlock
120607 TV #2 Axis Interlock
120608 TV #2 Axis Interlock Overload Safety Shutoff Detection (Safety Relay)
120609 TV #2 Axis Interlock
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-25 AHI01EGP
Error ID Item Description
12060a TV #2 Axis Interlock
121001 TV #2 Precheck Zeroing not completed within specified time. (Current
Position Indefinite)
121002 TV #2 Precheck Pallet not drawn normally.
121003 TV #2 Precheck Multi-layer tray feeder door opened. (K504)
121004 TV #2 Precheck Safty relay off; K502
121005 TV #2 Precheck Pallet installation error detected (on operator or
drawing side).; BPH504/505
121006 TV #2 Precheck Rack shutter opened.; BPS502/504
121007 TV #2 Precheck Pallet chuck opened.; BPS512
121008 TV #2 Precheck L1 Axis Zeroing not completed
121009 TV #2 Precheck
12100a TV #2 Precheck
12100b TV #2 Precheck Pallet detected.; BPS514
12100c TV #2 Precheck
12100d TV #2 Precheck
12100e TV #2 Precheck
12100f TV #2 Precheck Incorrect No. of Drawing Step
122001 TV #2 Precheck
122002 TV #2 Precheck
122003 TV #2 Precheck
122004 TV #2 Precheck
122005 TV #2 Precheck Pallet installation error detected on operator side.;
BPH505
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-26 AHI01EGP
Error ID Item Description
122006 TV #2 Precheck Rack shutter closed.; BPS501/503
122007 TV #2 Precheck
122008 TV #2 Precheck
122009 TV #2 Precheck
12200a TV #2 Precheck
12200b TV #2 Precheck Pallet found on returning step (BPH520, 521)
12200c TV #2 Precheck
12200d TV #2 Precheck
12200e TV #2 Precheck
12200f TV #2 Precheck
123001 TV #2 Precheck
123002 TV #2 Precheck
123003 TV #2 Precheck
123004 TV #2 Precheck
123005 TV #2 Precheck Pallet installation error detected on traverse side;
BPH504
123006 TV #2 Precheck
123007 TV #2 Precheck
123008 TV #2 Precheck
123009 TV #2 Precheck
12300a TV #2 Precheck
12300b TV #2 Precheck
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-27 AHI01EGP
