2.3 Precautionary Items during Operation • When the tower light (green) is "ON" or "ON and OFF" (flickering), it shows that the static machine is in the "automatic" mode (awaiting mode). 031…

2.3 Precautionary Items during Operation

• Ensure personnel (part of body and clothes) and foreign objects remain

clear of the moving parts of the machine.

• Keep your face and hands away from any moving parts of the machine

during operation.

0311-003 16

AHI01EGP

Fig. X7

• When there is a problem with the machine, locate the cause and assess

the condition. After the problem has been rectified, turn off power supply

(if required) and follow reset procedures.

Refer to "Section 4 Maintenance and Troubleshooting" for details.

Power OFF Mode

Power Breaker

Fig. X7-1

WARNING

2.3 Precautionary Items during Operation

• When the tower light (green) is "ON" or "ON and OFF" (flickering), it

shows that the static machine is in the "automatic" mode (awaiting mode).

0311-003 17

AHI01EGP

Mispicked Component

• When a pick-up error has occurred, be sure to remove the mispicked

components before starting the automatic operation.

Fig. X8

CAUTION

2.4 Precautionary Measures before Maintenance Work

0311-003 18 AHI01EGP

• Only qualified personnel should perform maintenance work care-

fully in compliance

with the specified procedures.

Air Source Section

• Before performing maintenance work, turn off the power and

air sources and lock the power breaker using the padlock.

• Designate a person who can have charge of the padlock key.

• If the provided padlock is lost or damaged, purchase its sub-

stitute.

Power Supply Section

Main Valve

Padlock

(630 061 9737)

Power Breake

Padlock

(630 061 9737)

Fig. X9

Fig. X10

WARNING
