OM-1078-002 - 第191页
Error ID Item Description 14f001 Elevator #2 Axis Operation Error Tray No. Error 14f002 Elevator #2 Axis Operation Error Step No. Error 14f003 Elevator #2 Axis Operation Error Designated speed error . 14f004 Elevator #2 …
Error ID Item Description
14200e Elevator #2 Axis Check to Move
14200f Elevator #2 Axis Check to Move
143001 Elevator #2 Axis Check to Move
143002 Elevator #2 Axis Check to Move
143003 Elevator #2 Axis Check to Move
143004 Elevator #2 Axis Check to Move
143005 Elevator #2 Axis Check to Move Pallet installation error detected on traverse side;
BPH504
143006 Elevator #2 Axis Check to Move
143007 Elevator #2 Axis Check to Move
143008 Elevator #2 Axis Check to Move
143009 Elevator #2 Axis Check to Move
14300a Elevator #2 Axis Check to Move
14300b Elevator #2 Axis Check to Move
14300c Elevator #2 Axis Check to Move
14300d Elevator #2 Axis Check to Move
14300e Elevator #2 Axis Check to Move
14300f Elevator #2 Axis Check to Move
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-45 AHI01EGP
Error ID Item Description
14f001 Elevator #2 Axis Operation Error Tray No. Error
14f002 Elevator #2 Axis Operation Error Step No. Error
14f003 Elevator #2 Axis Operation Error Designated speed error.
14f004 Elevator #2 Axis Operation Error Destination error
14f005 Elevator #2 Axis Operation Error Destination error
14f006 Elevator #2 Axis Operation Error Overtime in Operation
14f007 Elevator #2 Axis Operation Error Operation error
14f008 Elevator #2 Axis Operation Error Emergency stop
14f009 Elevator #2 Axis Operation Error
14f00a Elevator #2 Axis Operation Error
14f00b Elevator #2 Axis Operation Error
14f00c Elevator #2 Axis Operation Error
14f00d Elevator #2 Axis Operation Error
14f00e Elevator #2 Axis Operation Error
14f00f Elevator #2 Axis Operation Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-46 AHI01EGP
Error ID Item Description
6f0001 Tray 1 Operation Error The elevator stopped running in an error condition.
6f0002 Tray 1 Operation Error The traverse stopped running in an error condition.
6f0003 Tray 1 Operation Error Rack Shutter Opening Out of Time Limit
6f0004 Tray 1 Operation Error Rack Shutter Closing Out of Time Limit
6f0005 Tray 1 Operation Error Pallet Chuck Opening Out of Time Limit
6f0006 Tray 1 Operation Error Pallet Chuck Closing Out of Time Limit
6f0101 Tray 1 System Error Tray No. Error
6f0102 Tray 1 System Error Feeder No. Error
6f0103 Tray 1 System Error Step No. Error
6f0104 Tray 1 System Error
6f0105 Tray 1 System Error
6f0106 Tray 1 System Error
6f0107 Tray 1 System Error
6f0108 Tray 1 System Error
6f0109 Tray 1 System Error
6f010a Tray 1 System Error
6f010b Tray 1 System Error
6f010c Tray 1 System Error
6f010d Tray 1 System Error
6f010e Tray 1 System Error
6f010f Tray 1 System Error
6f0201 Tray 1 Precheck Error L1 Axis Zeroing not completed
2.3 Troubleshooting after "ERROR" Window (Error ID)
