Error ID Item Description
6f1301 Tray 1 Pallet Drawout Error Elevator Drawout Level Movement Error (Before
Operation)
6f1302 Tray 1 Pallet Drawout Error Elevator Drawout Level Movement Error (During
Operation)
6f1303
6f1401 Tray 1 Pallet Drawout Error No Pallet at Start of Drawout Operation
6f1402 Tray 1 Pallet Drawout Error Traverse Chuck Position Movement Error (Before
Operation)
6f1403 Tray 1 Pallet Drawout Error Traverse Chuck Position Movement Error (During
Operation)
6f1404 Tray 1 Pallet Drawout Error Traverse Drawout Position Movement Error (Before
Operation)
6f1405 Tray 1 Pallet Drawout Error Traverse Drawout Position Movement Error (During
Operation)
6f1406 Tray 1 Pallet Drawout Error No Pallet at End of Drawout Operation
6f1407 Tray 1 Pallet Drawout Error
6f1501 Tray 1 Elevator Change Position Change Position Movement Error (Before Operation)
Movement Error
6f1502 Tray 1 Elevator Change Position Change Position Movement Error (During Operation)
Movement Error
6f1503 Tray 1 Elevator Change Position
Movement Error
6f1601 Tray 1 Feeder Zeroing Error The rack shutter did not open within the specified
time. (0101)
6f1602 Tray 1 Feeder Zeroing Error The pallet chuck did not close within the specified
time. (0201)
6f1603 Tray 1 Feeder Zeroing Error A pallet was detected with the pallet not being drawn
out. (0202)
6f1604 Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0203)
6f1605 Tray 1 Feeder Zeroing Error An ejected pallet wad detected with the pallet not
being drawn out. (0301)
6f1606 Tray 1 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0302)
6f1607 Tray 1 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0303)
6f1608 Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0401)
6f1609 Tray 1 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0402)
6f160a Tray 1 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0403)
6f160b Tray 1 Feeder Zeroing Error The pallet wad not detected. The drawout log was
cleared. (BPH514) (501)
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-49 AHI01EGP
Error ID Item Description
6f160c Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0601)
6f160d Tray 1 Feeder Zeroing Error The pallet was not detected. Sensor Error! (BPH514)
(0701)
6f160e Tray 1 Feeder Zeroing Error The pallet was not detected within the specified time.
(0702)
6f160f Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0901)
6f1610 Tray 1 Feeder Zeroing Error The chuck did not open within the specified time.
(1001)
6f1611 Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (1101)
6f1613 Tray 1 Feeder Zeroing Error An ejected pallet was detected. (1202)
6f1614 Tray 1 Feeder Zeroing Error The pallet was not detected. (1203)
6f1615 Tray 1 Feeder Zeroing Error The elevator could not move to the return step
becaue the pallet was not drawn out. (1301)
6f1616 Tray 1 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (1302)
6f1617 Tray 1 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (1401)
6f1618 Tray 1 Feeder Zeroing Error The rack shutter did not open within the specified
time. (1501)
6f1619 Tray 1 Feeder Zeroing Error The chuck did not open within the specified time.
(1502)
6f161a Tray 1 Feeder Zeroing Error The rack shutter did not close within the specified
time. (1601)
6f161b Tray 1 Feeder Zeroing Error The chuck did not close within the specified time.
(1602)
6f161c Tray 1 Feeder Zeroing Error The rack shutter did not close within the specified
time. (1701)
6f161d Tray 1 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (0304)
6f161e Tray 1 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (1801)
6f161f Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2000)
6f1620 Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L2 axis was not located at its origin.
(2001)
6f1621 Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2100)
6f1622 Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L2 axis was not located at its origin.
(2101)
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-50 AHI01EGP
Error ID Item Description
6f1623 Tray 1 Feeder Zeroing Error A tray was detected at the return position. (1503)
6f1624 Tray 1 Feeder Zeroing Error The chuck did not close within the specified time.
(2201)
6f1625 Tray 1 Feeder Zeroing Error The rack shutter did not close within the specified
time. (2301)
6f1626 Tray 1 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (2401)
6f1627 Tray 1 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (2501)
6f1628 Tray 1 Feeder Zeroing Error Defective Pallet Detection Sensor (BPH514) (1603)
6f1629 Tray 1 Feeder Zeroing Error Defective Pallet Detection Sensor (BPH514) (2601)
6f162a Tray 1 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2701)
6f162b Tray 1 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2801)
6f162c Tray 1 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2901)
6f162d Tray 1 Feeder Zeroing Error Origin Not Detected by Sensor (3001)
6f1701 Tray 1 Feeder Zeroing Error A palllet was detected at the elevator origin.
(BPH514) (5001)
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-51 AHI01EGP
