Error ID Item Description 700204 Tray 2 Precheck Error EV1 Axis Zeroing not completed 700205 Tray 2 Precheck Error 700206 Tray 2 Precheck Error 700207 Tray 2 Precheck Error 700601 Tray 2 Interlock 700602 Tray 2 Interlock…
Error ID Item Description
700001 Tray 2 Operation Error The elevator stopped running in an error condition.
700002 Tray 2 Operation Error The traverse stopped running in an error condition.
700003 Tray 2 Operation Error Rack Shutter Opening Out of Time Limit
700004 Tray 2 Operation Error Rack Shutter Closing Out of Time Limit
700005 Tray 2 Operation Error Pallet Chuck Opening Out of Time Limit
700006 Tray 2 Operation Error Pallet Chuck Closing Out of Time Limit
700101 Tray 2 System Error Tray No. Error
700102 Tray 2 System Error Feeder No. Error
700103 Tray 2 System Error Step No. Error
700104 Tray 2 System Error
700105 Tray 2 System Error
700106 Tray 2 System Error
700107 Tray 2 System Error
700108 Tray 2 System Error
700109 Tray 2 System Error
70010a Tray 2 System Error
70010b Tray 2 System Error
70010c Tray 2 System Error
70010d Tray 2 System Error
70010e Tray 2 System Error
70010f Tray 2 System Error
700201 Tray 2 Precheck Error L1 Axis Zeroing not completed
700202 Tray 2 Precheck Error L2 Axis Zeroing not completed
700203 Tray 2 Precheck Error TV1 Axis Zeroing not completed
0109-001 4-52 AHI01EGP
2.3 Troubleshooting after "ERROR" Window (Error ID)
Error ID Item Description
700204 Tray 2 Precheck Error EV1 Axis Zeroing not completed
700205 Tray 2 Precheck Error
700206 Tray 2 Precheck Error
700207 Tray 2 Precheck Error
700601 Tray 2 Interlock
700602 Tray 2 Interlock
700603 Tray 2 Interlock
700604 Tray 2 Interlock
700605 Tray 2 Interlock
701001 Tray 2 Supply Operation Error
701002 Tray 2 Supply Operation Error Drawout Tray Step No. Mismatch (Returning)
701003 Tray 2 Supply Operation Error Drawout Tray Step No. Mismatch (Returning)
701004 Tray 2 Supply Operation Error Illegal Operation Mode (System)
701005 Tray 2 Supply Operation Error Indefinite TV-Axis Position
701101 Tray 2 Pallet Returning Error Elevator Moving Position Error
701102 Tray 2 Pallet Returning Error Elevator Operation Error
701103 Tray 2 Pallet Returning Error
701201 Tray 2 Pallet Returning Error No Pallet at Start of Returning Operation
701202 Tray 2 Pallet Returning Error Prechecking Error
701203 Tray 2 Pallet Returning Error Traverse Operation Error
701204 Tray 2 Pallet Returning Error No Pallet at Start and End of Returning Operation
701205 Tray 2 Pallet Returning Error
701301 Tray 2 Pallet Drawout Error Elevator Drawout Level Movement Error (Before
Operation)
701302 Tray 2 Pallet Drawout Error Elevator Drawout Level Movement Error (During
Operation)
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-53 AHI01EGP
Error ID Item Description
701303
701401 Tray 2 Pallet Drawout Error No Pallet at Start of Drawout Operation
701402 Tray 2 Pallet Drawout Error Traverse Chuck Position Movement Error (Before
Operation)
701403 Tray 2 Pallet Drawout Error Traverse Chuck Position Movement Error (During
Operation)
701404 Tray 2 Pallet Drawout Error Traverse Drawout Position Movement Error (Before
Operation)
701405 Tray 2 Pallet Drawout Error Traverse Drawout Position Movement Error (During
Operation)
701406 Tray 2 Pallet Drawout Error No Pallet at End of Drawout Operation
701407 Tray 2 Pallet Drawout Error
701501 Tray 2 Elevator Change Positoin Change Position Movement Error (Before Operation)
Movement Error
701502 Tray 2 Elevator Change Positoin Change Position Movement Error (During Operation)
Movement Error
701503 Tray 2 Elevator Change Positoin
Movement Error
701601 Tray 2 Feeder Zeroing Error The rack shutter did not open within the specified
time. (0101)
701602 Tray 2 Feeder Zeroing Error The pallet chuck did not close within the specified
time. (0201)
701603 Tray 2 Feeder Zeroing Error A pallet was detected with the pallet not being drawn
out. (0202)
701604 Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0203)
701605 Tray 2 Feeder Zeroing Error An ejected pallet wad detected with the pallet not
being drawn out. (0301)
701606 Tray 2 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0302)
701607 Tray 2 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0303)
701608 Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0401)
701609 Tray 2 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0402)
70160a Tray 2 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0403)
70160b Tray 2 Feeder Zeroing Error The pallet wad not detected. The drawout log was
cleared. (BPH514) (501)
70160c Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0601)
70160d Tray 2 Feeder Zeroing Error The pallet was not detected. Sensor Error! (BPH514)
(0701)
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-54 AHI01EGP
