Error ID Item Description 701625 Tray 2 Feeder Zeroing Error The rack shutter did not close within the specified time. (2301) 701626 Tray 2 Feeder Zeroing Error The elevator movement to the return step ended in an error …
Error ID Item Description
70160e Tray 2 Feeder Zeroing Error The pallet was not detected within the specified time.
(0702)
70160f Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0901)
701610 Tray 2 Feeder Zeroing Error The chuck did not open within the specified time.
(1001)
701611 Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (1101)
701613 Tray 2 Feeder Zeroing Error An ejected pallet was detected. (1202)
701614 Tray 2 Feeder Zeroing Error The pallet was not detected. (1203)
701615 Tray 2 Feeder Zeroing Error The elevator could not move to the return step
becaue the pallet was not drawn out. (1301)
701616 Tray 2 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (1302)
701617 Tray 2 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (1401)
701618 Tray 2 Feeder Zeroing Error The rack shutter did not open within the specified
time. (1501)
701619 Tray 2 Feeder Zeroing Error The chuck did not open within the specified time.
(1502)
70161a Tray 2 Feeder Zeroing Error The rack shutter did not close within the specified
time. (1601)
70161b Tray 2 Feeder Zeroing Error The chuck did not close within the specified time.
(1602)
70161c Tray 2 Feeder Zeroing Error The rack shutter did not close within the specified
time. (1701)
70161d Tray 2 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (0304)
70161e Tray 2 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (1801)
70161f Tray 2 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2000)
701620 Tray 2 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L2 axis was not located at its origin.
(2001)
701621 Tray 2 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2100)
701622 Tray 2 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L2 axis was not located at its origin.
(2101)
701623 Tray 2 Feeder Zeroing Error A tray was detected at the return position. (1503)
701624 Tray 2 Feeder Zeroing Error The chuck did not close within the specified time.
(2201)
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-55 AHI01EGP
Error ID Item Description
701625 Tray 2 Feeder Zeroing Error The rack shutter did not close within the specified
time. (2301)
701626 Tray 2 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (2401)
701627 Tray 2 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (2501)
701628 Tray 2 Feeder Zeroing Error Defective Pallet Detection Sensor (BPH514) (1603)
701629 Tray 2 Feeder Zeroing Error Defective Pallet Detection Sensor (BPH514) (2601)
70162a Tray 2 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2701)
70162b Tray 2 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2801)
70162c Tray 2 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2901)
70162d Tray 2 Feeder Zeroing Error Origin Not Detected by Sensor (3001)
701701 Tray 2 Feeder Zeroing Error A palllet was detected at the elevator origin.
(BPH514) (5001)
2.3 Troubleshooting after "ERROR" Window (Error ID)
0109-001 4-56 AHI01EGP
AHI01EGP
Section 5
Pneumatic and Electrical Diagrams
This section describes the pneumatic diagram, the parts
location, the location of sensors and loads, the electrical
circuit diagrams, etc.
As this section contains highly sophisticated contents, it
should carefully be referred to.
0311-002 5-1
