2.4 Precautionary Measures before Maintenance Work
2.4 Precautionary Measures before Maintenance Work
0311-003 18 AHI01EGP
• Only qualified personnel should perform maintenance work care-
fully in compliance
with the specified procedures.
Air Source Section
• Before performing maintenance work, turn off the power and
air sources and lock the power breaker using the padlock.
• Designate a person who can have charge of the padlock key.
• If the provided padlock is lost or damaged, purchase its sub-
stitute.
Power Supply Section
Main Valve
Padlock
(630 061 9737)
Power Breake
r
Padlock
(630 061 9737)
Fig. X9
Fig. X10
WARNING
WARNING
0311-003 19 AHI01EGP
2.5 Pre-Installation Checks
If the machine is installed in unsatisfactory environmental conditions, it
may malfunction due to damage or breakdown.
To avoid this, make preparations to install the machine as follows.
If the machine is scheduled to be transferred to another place, please
contact our marketing department or sales agency beforehand.
• Select a place solid enough to support
the weight of the machine.
Ref.: It is recommended that the ma-
chine should be installed on the
first floor. When the machine has
to be installed on a floor other
than the first one, please contact
our marketing department or
sales agency for details.
• Avoid any place that vibrates severely.
• Ambient temperature must be
20±10°C and humidity 30% to 80%.
Any dew condensation must be
avoided.
• Ensure that the selected place is free
of electric noise.
Precautionary measures (prevention of
noise generation, etc.) must be taken
for other equipment to prevent malfunc-
tions.
2.5 Pre-Installation Checks
Fig. X11
Fig. X13
Fig. X12
Fig. X14
3. About Warning Labels
Please read "3.1 Warning Label Positions" and "3.2 Warning Labels and
Description" carefully to fully understand the meaning of each precau-
tionary point for safety precautions.
3.1 Warning Label Positions
The warning labels are affixed to hazardous and special attention-re-
quired areas.
Refer to "3.2 Warning Labels and Description" for details.
3. About Warning Labels
0311-003 20 AHI01EGP
Fig. X15 Fig. X16
*2
*3
*1-2
*1-2
*1-2
*1-2
*5
*2
*3
Fig. X17
*4
*6
*5
*1-1
*2
*3
