Section 1
Operation (Operator)
0311-002 1-1 AHI01EGP
This section describes the fundamentals for those who use
the multi-layer tray feeder for the first time.
Coverage: This covers the outline of the machine, the prepa-
ratory and ending procedures of automatic op-
eration, and the troubleshooting on simple errors.
0311-001 1-1-1 AHI01EGP
1. Scope
1.1 What is Multi-Layer Tray Feeder?
The multi-layer tray feeder supplies tray components to TIM-X100 (main
machine) so that the placement heads can pick up the tray components
directly.
Fig. A1
1. Scope
0311-003 1-2 AHI01EGP
Tray Components
Tray
Pallet
