3-70 AIVEDT -ID 3.2 Repetitive Patterns (Image Recognition Enabled) (1) Information on Pattern Program Creation • PCB Size, Packaged Posture and ID of Components, and Fiducial Marks The data is the same as those describe…
3-69
AIVEDT-ID
(4) Placement Feeder Location Data
Table 3C9
Fdr No. Component ID C Comment Feeder Fixed
Feeder
Alternate
Fdr No.
101 TANA3216C0HIT - Disable Disable 000
103 TR2012-3B0HIT
-L2 - Disable Disable 000
105
SOP008-B02SAN32E E Disable Disable 000
(5) P-data (U01)
•
Unit Control
Table 3C10
Unit Control Offset X [mm] Offset Y [mm] Offset Z [deg] Offset H [mm]
Placement +000.000 +000.000 +000.00 +0.000
•
Unit PCB Fiducial
Set "Disable" in this text box.
Do not set any parameters in the other text boxes.
•
P-data
Table 3C11
P-No. X [mm] Y [mm] Z [deg] H [mm] Fdr No. C Comment
1 X
1
Y
1
+000.00 +0.000 101 -
2 X
2
Y
2
+090.00 +0.000 103 -
3 X
3
Y
3
+180.00 +0.000 105 -
4 +000.000 +000.000 +000.00 +0.000 000 E
(6) O-data (U01)
Do not create this data.
0606-009
3.1 Single Pattern (Global Recognition Enabled)
3-70
AIVEDT-ID
3.2 Repetitive Patterns (Image Recognition Enabled)
(1) Information on Pattern Program Creation
•
PCB Size, Packaged Posture and ID of Components, and Fiducial
Marks
The data is the same as those described in "3.1 Single Pattern
(Global Recognition Enabled)".
•
Placement Coordinates, Angles, and Fiducial Mark Coordinates
Placement
Coordinate
Reference
Pattern 3
Pattern 2 Pattern 1
Fiducial Marks
Pattern Origin (0X
3, 0Y3) (0X2, 0Y2) (0X1, 0Y1)
Fig. 3C54 Whole View
X3
Y3
X2
Y2
X1
OX1
Y1
OY1
FX1
FY1
FY2
FX2
Placement
Coordinate
Reference
Fig. 3C55 Pattern 1 (Magnified View)
0606-009
3.2 Repetitive Patterns (Image Recognition Enabled)
3-71
AIVEDT-ID
•
List of Required Data
Table 3C12
Pattern Program Required Data
Operation Data PCB Data
PEC Recognition Data
PEC Recognition Mark Data
Setup Data Note (a)
Placement
Head/Nozzle Data
Heads 1 through 4
Placement Feeder
Location Data
Feeder Bases #1 through #4
Placement Data U01 P-data P-data
Unit Control Note (b)
Unit PCB Fiducial
O-data
Placement Data Un P-data P-data ×
Unit Control ×
Unit PCB Fiducial ×
O-data ×
Note
(a) Create this data for automatic conveyor width adjustment.
(b) Specify these parameters (data) according to the situational changes.
