3-70
AIVEDT-ID
3.2 Repetitive Patterns (Image Recognition Enabled)
(1) Information on Pattern Program Creation
•
PCB Size, Packaged Posture and ID of Components, and Fiducial
Marks
The data is the same as those described in "3.1 Single Pattern
(Global Recognition Enabled)".
•
Placement Coordinates, Angles, and Fiducial Mark Coordinates
Placement
Coordinate
Reference
Pattern 3
Pattern 2 Pattern 1
Fiducial Marks
Pattern Origin (0X
3, 0Y3) (0X2, 0Y2) (0X1, 0Y1)
Fig. 3C54 Whole View
X3
Y3
X2
Y2
X1
OX1
Y1
OY1
FX1
FY1
FY2
FX2
Placement
Coordinate
Reference
Fig. 3C55 Pattern 1 (Magnified View)
0606-009
3.2 Repetitive Patterns (Image Recognition Enabled)
3-71
AIVEDT-ID
•
List of Required Data
Table 3C12
Pattern Program Required Data
Operation Data PCB Data
PEC Recognition Data
PEC Recognition Mark Data
Setup Data Note (a)
Placement
Head/Nozzle Data
Heads 1 through 4
Placement Feeder
Location Data
Feeder Bases #1 through #4
Placement Data U01 P-data P-data
Unit Control Note (b)
Unit PCB Fiducial
O-data
Placement Data Un P-data P-data ×
Unit Control ×
Unit PCB Fiducial ×
O-data ×
Note
(a) Create this data for automatic conveyor width adjustment.
(b) Specify these parameters (data) according to the situational changes.
0606-009
3.2 Repetitive Patterns (Image Recognition Enabled)
3-72
AIVEDT-ID
(2) Creation of Operation Data
•
PCB Data
Create the data in the same way as described in "3.1 Single Pattern (Global
Recognition Enabled)".
•
PEC Recognition Data
Table 3C13
PEC recognition function Enable
Correction algorithm Standard
PEC recognition
Mode
Global Zone 1 Disable
Zone 2 Disable
Zone 3 Disable
Zone 4 Disable
Zone 5 Disable
Image Enable
Iocal Disable
Beam Stage 1 Automatic (1 or 2)
Stage 2 Automatic (1 or 2)
Sequence Stage 1 After Pick Up
Stage 2 After Pick Up
•
PEC Recognition Mark Data
Table 3C14
Mark
No.
Mark
Size
D1 [mm]
1 Round 1.00 0.00 0.00
000.00 05.0 Bright High Standard Standard
(Normal)
Mark
Type
Mark
Size
D2 [mm]
Mark
Size
D3 [mm]
Angle
[deg]
Window
Size
[mm]
Mark
Mark
Level
Lighting
Level
Coax
Lighting
Level
Ring
•
Setup Data
Create this data when the automatic setup function is used.
(3) Creation of Placement Head/Nozzle Data
Create the data in the same way as described in "3.1 Single Pattern (Global
Recognition Enabled)".
(4)
Creation of Placement Feeder Location Data
Create the data in the same way as described in "3.1 Single Pattern (Global
Recognition Enabled)".
