5-11
AIVEDT-ID
(11) Power on time
Shown is the period of time during which the control power of the
machine was working.
Note
Example: 10:03'50" (10 hours, 3 minutes, and 50 seconds)
Auto run time
Shown is the period of time during which the machine was running
automatically.
When a particular pattern program is set several times as current one,
the sum total is computed.
Placement time
Shown is the time required to finish a PCB (from the first to the last
component placement on one product PCB).
The essential component placement time is summed up. While
the machine is set in the "ST
OP" or the "PAUSE" mode or a step
operation is performed, the time is not measured.
This is used to calculate the average placement tact time per
component.
PCB transfer time
Shown is the period of time during which Conveyor NL, NR, NA,
NB, and NC are being activated.
PCB wait
Input wait
Shown is the period of time during which the machine was
completely in the waiting mode (the machine was waiting for a
PCB to be loaded from the input machine).
Output wait
Shown is the period of time during which the machine was
completely in the waiting mode (the machine was waiting for a
PCB to be unloaded to the output machine).
PEC/BBR
Shown is the period of time during which the machine is taking PEC
recognition and BBR detection actions.
Counted is the period of time during which the X/Y table starts moving
and the PEC recognition and BBR detection are completed.
0606-009
2.1 Machine Performance Data
5-12
AIVEDT-ID
Others
Shown is the period of time during which the X/Y beam takes
actions before component placement, the X/Y table returns after
component placement, etc.
Stop time
Shown is the period of time during which component placement
operation was interrupted for component replenishment, etc.
Error stop
Error alarm
Shown is the period of time during which an alarm (light tower
ON) is issued.
Recovery
Shown is the time between error cancellation and restart of
machine operation.
Feeder Reload
Shown is the time during which components were replenished.
Others
Shown is the period of time during which the machine has performed
the setup, program change, idling operations, etc.
(12) Maintenance time
Shown is the period of time during which the [SETUP] button on the
main menu bar is pressed.
(13) Warm-up run (Test Mode) time
The running time is counted when the machine is operated under the
following condition.
•
"Test Mode" is enabled in the "OPERATION MODE" window
.
•
The "PCB Transfer Dsbl." check box is ticked.
(State in which no PCB is put in and out)
(14) Test mode time
Shown is the period of time during which test run was performed
according to the test mode parameters.
0606-009
2.1 Machine Performance Data
5-13
AIVEDT-ID
(15) Total handling errors/Total components
Shown are the total number of pickup errors, the total number of
components to be picked up, and the percentage of picked components
per total number of pickup errors.
A: comp.missing (% of Total handling errors)
Shown are the number of component missing errors detected by the
linear measure detection sensor and the percentage of component
missing errors per total number of pickup errors.
B: comp. missing (% of Total handling errors)
Shown are the number of component missing errors detected in the
recognition process and the percentage of component missing errors per
total number of pickup errors.
C: comp. vertical (% of Total handling errors)
Shown are the number of vertical component errors detected by
the linear measure detection sensor and the percentage of vertical
component errors per total number of pickup errors.
D: comp. recog. (% of Total handling errors)
Shown are the number of errors detected in the recognition process and
the percentage of errors per total number of pickup errors.
E: comp. thick (% of Total handling errors)
Shown is the percentage of component thickness errors detected by the
linear measure detection sensor per total number of pickup errors.
F: pick-up diff (% of Total handling errors)
Shown are the number of pickup difference errors detected in the
recognition process and the percentage of the errors per total number of
pickup errors.
G: component posture (% of Total handling errors)
Shown are the number of reversed component and polarity judgment
errors detected in the recognition process and the percentage of the
errors per total number of pickup errors.
Total handling errors
Shown is the total number of component handling errors.
