6-63
AIVEDT-ID
[4] Simultaneous transfer setup
Set "Enable" or "Disable" to determine whether or not the PCB transfer
should be made simultaneously between the input and positioning
conveyors and between the positioning and output conveyors.
[5] Output conveyor PCB Out
Set "Disable" or "Enable" to determine whether or not a disengaged
PCB should be detected in the output conveyor section.
[6] Furnace Signal Check
Set "Disable" or Enable" to determine whether or not the furnace signal
check function should be activated.
Note
When "SMEMA" is set in the "Input mode" text box of the label "Input
Setup" or in the "Output mode" text box of the label "Output Setup", this
function cannot be used.
2.2 Auto Operation
0606-009
6-64
AIVEDT-ID
[7] Input Setup
Input mode
Select a parameter according to the PCB unloading system of the input
machine.
Conveyor
The input machine is activated to receive a PCB from the input
machine when the PCB transfer signal is received from the input
machine.
Pusher
The pusher of the input machine forces a PCB out to the input
conveyor of the machine.
When the PCB detection sensor (for the pusher) is not provided at
the inlet side of the input conveyor
, do not set "Pusher" in the text
box.
SMEMA
PCBs are transferred according to the "SMEMA" standard.
Pusher delay timer [sec]
When "Pusher" is set in the "Input mode" text box of the label "Input
Setup", it is required to specify the delay (waiting) time for the loading
action to start after the inlet sensor has detected a PCB.
PCB delivery Position
Set the position where PCBs are received.
T
ransfer speed
Set the PCB transfer speed.
•
Default:
300 [mm/sec]
2.2 Auto Operation
0606-009
6-65
AIVEDT-ID
[8] Output Setup
Output mode
Select "Standard", "Interval", or "SMEMA" to determine how to
transfer PCBs from the main machine to the output machine.
Standard
When the output machine is manufactured by us, set "Standard" in
the text box.
When the work request signal is received from the output machine,
the PCB transfer signal of the machine is turned ON and a PCB is
transferred to the output machine by the output conveyor
.
When the work request signal is not turned OFF within the specified
time after a PCB unloading action has started, the machine stops in
an error condition.
Interval
When the work request signal of the output machine is turned ON,
PCBs on the machine side are transferred to the output machine.
The conveyor stops when the output conveyor timer 1 has reached
the specifi
ed time.
The machine starts its unloading actions when the unloading
condition is fulfilled after the conveyor has stopped running and
the time specified in the "Output interval timer [sec]" text box has
elapsed.
Note
No error detection is made.
SMEMA
PCBs are transferred according to the "SMEMA" standard.
Output interval timer [sec]
When "Interval" is set in the "Output mode" text box, set the time as
interval time for PCB unloading actions.
PCB delivery Position [mm]
Set the position where PCBs are received.
T
ransfer speed [mm/sec]
Set the PCB transfer speed.
•
Default:
300 [mm/sec]
Note
When the unloading system of the output machine is used in a
mode other than the standard one and the PCB transfer speed of
the output machine is slow, the transfer speed must be adjusted
to one on the output machine side.
A PCB may be trapped during the arrangement of the conveyor
Y position.
2.2 Auto Operation
0606-009
