6-94 AIVEDT -ID 0606-009 7. Network Setting The corresponding window enables you to connect the computer system of the machine to the local network (Ethernet LAN). When the [NETWK. DT .] button on the "MACH SET"…
6-93
AIVEDT-ID
•
How to specify the date and time
Procedure
(1) When the [Year] button is pressed, the "Year" edit window opens.
(2) Enter a year in the entry field of the "Year" edit window and press the [Set]
button.
The entered year appears in the corresponding text box.
(3) Follow the same procedure to specify a month, a day
, hours, minutes, and
seconds.
(4) Select the proper time zone from the "Time Zone" list pane.
(5)
When the [SET] button is pressed, the settings are determined.
0606-009
6. Date & Time Setting
6-94
AIVEDT-ID
0606-009
7. Network Setting
The corresponding window enables you to connect the computer system of
the machine to the local network (Ethernet LAN).
When the [NETWK. DT.] button on the "MACH SET" menu bar is pressed,
the "Network Set" window appears.
The "Network Set" window is provided with three tab sheets.
(1) In the "Identification" tab sheet, specify the name of the computer in
this machine.
Fig. 3F84 "Network Set" Window ("Identification" Tab Sheet)
(2) In the "IP Address" tab sheet, specify the IP address to be used.
Fig. 3F85 "Network Set" Window ("IP Address" Tab Sheet)
7. Network Setting
6-95
AIVEDT-ID
(3) In the "DNS" tab sheet, specify the domain name system (host and
domain names).
Fig. 3F86 "Network Set" Window ("DNS" Tab Sheet)
(4) When the [SET] button is pressed, the network is constructed according
to the specified data.
When the [Cancel] button is pressed, the specified settings are canceled.
0606-009
7. Network Setting
