Note
The Available connections count on the Add system page indicates how many Machine Manager connections you can add with the
current license. Confirm you have available connections to proceed.
Step 1: IP Address
Enter the IP address of the PSV system in the provided field. If you're unsure of the IP address, here's how you can find it on a Windows
computer:
1. On the PSV system (Machine Manager instance) to add to ConneX Server, open the Command Prompt by typing cmd in the
Windows search bar, then select Command Prompt from the results.
2. In the Command Prompt window, type the command ipconfig, and press Enter.
3. Look for the IPv4 Address entry for the network adapter used to connect to the PSV system (which is the IP address you enter into
the Add system wizard).
Step 2: System Details
If the connection to the PSV system is successful, the wizard displays a table with details of the new system. Confirm the table shows the
intended system to add; else click Back to confirm the IP address.
Detail Description
System Name The ConneX given name of the system.
Machine Serial Number The serial number of the system.
Hostname The name of the host used by Windows.
System Type The type of system (e.g. PSV7000, PSV5000, etc.)
Step 3: Options
Set additional options to customize the connection process.
Option Description
Add
system
X
Available
connections:
99995
/
99999
2
3
4
IP
Address
System
Details
Options
Finish
139
138.21.6
Step
1
of
4
NEXT
IP
address
Adopt system after
connecting?
Enable to adopt the system and allow ConneX Server to start receiving messages immediately; Disable to simply
add the system now (ex. ConneX data transfer to be enabled later)
System Name Type the name of the system.
Option Description
Step 4: Finish
If the setup wizard displays the following page, then the Machine Manager system is successfully added to ConneX Server. At this point,
you can click Finish to exit the wizard.
However, in some cases, a warning message might appear indicating that the adoption was not successful because the system is already
adopted. In such cases, please follow the troubleshooting steps for System is adopted by another ConneX Service
A notification in the lower-right corner also indicates the success or failure of the add system operation.
To ensure/enable ConneX data transfer for the added Machine Manager, you must Adopt it from the ConneX Server (if not already
adopted):
1. From the Managepage, click the new Machine Manager/PSV System.
Add
system
X
Available
connections:
99995
/
99999
IP
Address
System
Details
Options
Finish
System
added
successfully
Click
Finish
to
close
the
dialog
step
4
0f
4
FINISH
2. In the selected system tile, click Adopt.
Disable Machine Manager Data Transfer
To disable ConneX data transfer, go to the Manage page and select/click the PSV System for which to stop/pause data transfer.
In the system tile, click Forget.
