SM Tape Feeder-2nd - 第121页

S A MS U N G T E C H W I N NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK 21 T󰚟Link󰚟5󰚟Ass'y󰚟-󰚟(J9065297A) 1 J7066319A T󰚟LINK󰚟5 1 SM1-MF32-032 2 J7066320A SW󰚟BLOCK 1 SM1-MF32-059 3 J7066321A SW󰚟BLOCK󰚟PIN 2 …

100%1 / 160
S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
4
J1301023
E󰚟RING󰚟3
5
J7066121A
SPRING󰚟PIN󰚟4T
2 SM1-MF12-136
6
FLAT󰚟HEAD󰚟CAP󰚟SCREW
1 M4*8
7
J7066240A
REEL󰚟BRAKE-32
1
SM1-MF32-017
8
J9065796A
STOPPER󰚟IN󰚟PIN2
1 TF12-N221
9
REEL󰚟BRACKET󰚟SPRING
1
SM1-MF32-017-02
17
Stop󰚟Pawl󰚟Rivet󰚟Ass'y󰚟-󰚟(J9065225A)
1
J7066154A
STOP󰚟PAWL
1
SM1-MF32-004
J7066368A
STOP󰚟PAWL-H
1
SM1-MF32H-004
(Half󰚟Pitch󰚟Type󰚟EXCLUSIVE)
2
J7066156A
STOP󰚟PAWL󰚟PIN
1
SM1-MF32-066
18
Upper󰚟I/G󰚟Plate󰚟Ass'y󰚟-󰚟(J9065240A)
1
J2500469A PAWL󰚟LEVER 1 TF12-150K
2
J7065786A
FORMING󰚟BRACKET󰚟BUSH
1 TF12-N210
3
J7065788A
GEAR󰚟SHAFT-1
1 TF08-103KA
4
J2500448A
PLANET󰚟GEAR
1 TF08-100K
5
J1301023
E󰚟RING󰚟3
1
6
J6601105A
ONE󰚟WAY󰚟BEARING
1
HF0406(KFA)
19
Reel󰚟Stopper󰚟Ass'y󰚟-󰚟(J9065205A)
1
STOPPER󰚟INNER
1
TF12-N218
2
J7065800A
STOPPER󰚟OUT󰚟RATCHET
1
TF12-N225
3
J7065795A
STOPPER󰚟IN󰚟PIN󰚟1
2
TF12-N220
4
J7065798A
STOPPER󰚟OUT󰚟PIN
1 TF12-N223
5
J7065797A
STOPPER󰚟IN󰚟BUSH
1
TF12-N222
6 STOPPER󰚟OUTTER 1 TF12-N219
S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
21
T󰚟Link󰚟5󰚟Ass'y󰚟-󰚟(J9065297A)
1
J7066319A
T󰚟LINK󰚟5
1 SM1-MF32-032
2
J7066320A
SW󰚟BLOCK
1 SM1-MF32-059
3
J7066321A
SW󰚟BLOCK󰚟PIN
2
SM1-MF32-064
20
Cylinder󰚟Ass'y󰚟-󰚟(J9065286A)
1
AIR󰚟CYLINDER
1 C2J016-01-IJ1420
2
AIR󰚟CYLINDER󰚟ROD
3 J7066173A CYL󰚟BLOCK 1 SM1-MF32-013-01
4 J7066171A SPACE󰚟CYLINDER 1 SM1-MF32-033-06
5 J7066172A SPACE󰚟CYLINDER󰚟WASHER 1 SM1-MF32-033-07
6
SHAFT󰚟CYLINDER
1
7 J7066314A CYL󰚟BLOCK󰚟BUSH 1 SM1-MF32-033-05
8
C󰚟RING󰚟5
2
9 J7066170A PITCH󰚟CONTROL󰚟PLATE 1 SM1-MF32-011
10 J7066167A PITCH󰚟CONTROL󰚟PIN 1 SM1-MF32-046
22
Sprocket󰚟Block󰚟44󰚟Ass'y󰚟-󰚟(J9065254A󰚟)
1
J7066258A
SPROCKET󰚟BLOCK󰚟44
1
SM1-MF44-003-01
2
J7066153A
SPROCKET󰚟BLOCK󰚟BUSH
2
SM1-MF32-003-02
23
Sprocket󰚟Bush󰚟Ass'y󰚟-󰚟(J9065223A)
1 J7066151A SPROCKET󰚟BUSH 1 SM1-MF32-002-03
2
J7066141A SPROCKET-40 1 SM1-MF32-002-07
3
J7066142A
RATCHET-40
1 SM1-MF32-002-01
4
J7066143A
SPROCKET󰚟RIVET󰚟PIN
3 SM1-MF32-002-06
S AMS UNG TE CHWIN
33
37
33
30
95
100
97
96
35
42
40
38
104
108
104
108
108
36
103
103
111
34
34
34
39
41
93
92
31
92
92
31
92
92
45
44
43
48
47
102
102
102
102
102
90
92
50
46
32
83
49
84
