S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME
Q'TY
TYPE REMARK
0402 0603 2P 2P_L 4P 4P_L 4E 4E_L
1
TAPE󰚟GUIDE󰚟0402󰚟ASS'Y
10000000
See󰚟page󰚟'A-17'
TAPE󰚟GUIDE󰚟0603󰚟ASS'Y
01000000
See󰚟page󰚟'A-17'
TAPE󰚟GUIDE󰚟2P󰚟ASS'Y
00110000
See󰚟page󰚟'A-17'
TAPE󰚟GUIDE󰚟4P󰚟ASS'Y
000 1111
See󰚟page󰚟'A-17'
2
LOCKER󰚟ASS'Y
11111111
See󰚟page󰚟'A-17'
3
SPROCKET󰚟0402󰚟ASS'Y
10000000
See󰚟page󰚟'A-18'
SPROCKET󰚟2P󰚟ASS'Y
01110000
See󰚟page󰚟'A-18'
SPROCKET󰚟4P󰚟ASS'Y
00001111
See󰚟page󰚟'A-18'
4
PUSHER󰚟0402󰚟ASS'Y
10000000
See󰚟page󰚟'A-18'
PUSHER󰚟ASS'Y
01111111
See󰚟page󰚟'A-18'
5
DRAIN󰚟ASS'Y 11111111
See󰚟page󰚟'A-19'
6
FORMING󰚟ASS'Y
11111111
See󰚟page󰚟'A-19'
7
TOGGLE󰚟ASS'Y
11111111
See󰚟page󰚟'A-19'
8
HANDLE󰚟ASS'Y
11111111
(IT󰚟EXCLUSIVE)
See󰚟page󰚟'A-20'
HANDLE󰚟ASS'Y 11111111
(NON󰚟IT󰚟EXCLUSIVE)
See󰚟page󰚟'A-20'
9
HANGER󰚟ASS'Y
11101010
See󰚟page󰚟'A-21'
10
REEL󰚟ASS'Y
11111111
(IT󰚟EXCLUSIVE)
See󰚟page󰚟'A-21,󰚟A-22'
REEL󰚟ASS'Y 11111111
(NON󰚟IT󰚟EXCLUSIVE)
See󰚟page󰚟'A-21,󰚟A-22'
11
CYLINDER󰚟0402󰚟ASS'Y 10000000
See󰚟page󰚟'A-20'
CYLINDER󰚟0603󰚟ASS'Y 01000000
See󰚟page󰚟'A-20'
CYLINDER󰚟2P󰚟ASS'Y 00110011
See󰚟page󰚟'A-20'
CYLINDER󰚟4P󰚟ASS'Y 00001100
See󰚟page󰚟'A-20'
12
J9065156A
PROBER󰚟CABLE󰚟ASS'Y
11111111SM1-MF08-202󰚟(IT󰚟EXCLUSIVE)
J9065279A PROBER󰚟CABLE󰚟ASS'Y 11111111
SM1-MF08-230󰚟(NON󰚟IT󰚟EXCLUSIVE)
13
J9065157A
INDEXING󰚟SENSOR󰚟ASS'Y
11111111SM1-MF08-203
14
J7065992A
BOTTOM󰚟LOC󰚟PIN
11111111SM1-MF08-056
S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME
Q'TY
TYPE REMARK
0402 0603 2P 2P_L 4P 4P_L 4E 4E_L
15
J7065982A
CABLE󰚟COVER1
11111111SM1-MF08-044
16
J7065989A
CABLE󰚟COVER2
11111111SM1-MF08-052
17
J7066024A
COUPLER󰚟BKT1
11111111
SM1-MF08-090
18
J7065990A
CYL󰚟BKT󰚟SHAFT
11111111SM1-MF08-053
19
J7066042A
D-BKT󰚟SPRING
11111111SM1-MF08-127
20
J7066039A
D-LEVER󰚟SPRING
11111111
SM1-MF08-124
21
J7065993A
DRAIN󰚟BKT󰚟SHAFT
11111111SM1-MF08-057
22
J7265152A
DRAIN󰚟GEAR
11111111SM1-MF08-011
23
J7065954A DRAIN󰚟SHAFT1 11111111
SM1-MF08-012
24
J7065955A DRAIN󰚟SPACER 11111111
SM1-MF08-013
25
J7065978A
INSTALL󰚟GUIDE
11111111
SM1-MF08-040
26
J7066041A
LEVER2󰚟SPRING
11101010
SM1-MF08-126
27
J7065959A
LIMIT󰚟SHAFT
11111111SM1-MF08-017
28
J7065988A
LINK󰚟SHAFT󰚟COVER
11101010SM1-MF08-051
29
J7065980A
HANGER󰚟SHAFT󰚟GUIDE
11101010
SM1-MF08-042
30
J7065948A
LOCATION󰚟FLANGE
11111111SM1-MF08-006
31
J7066014A
LOCKER󰚟HINGE
22222222SM1-MF08-076
32
J7066046A
LOCKER󰚟LIMIT󰚟SPRING
11111111SM1-MF08-131
33
J7066043A
LOCKER󰚟SPRING
11111111SM1-MF08-128
34
J7066033A
LOCKER󰚟SPG󰚟PIN2
11111111SM1-MF08-101
35
J7065967A
LOCKER󰚟LIMIT
11111111SM1-MF08-025
36
J7066346A MAIN󰚟FRAME󰚟0402 10000000
SM1-MF08-001-1
J7165292A MAIN󰚟FRAME 01101010
SM1-MF08-001
J7165292D MAIN󰚟FRAME 00010101
SM1-MF08-001R3
37
J6711249A COUPLER󰚟PLUG 1 1 1 1 1
KS-4-M5-SA34268KR
38
J6601132A
ONE󰚟WAY󰚟BEARING
11111111
OWC8-16-5.5-L
39
J7066018A
P-LEVER󰚟SPG󰚟PIN󰚟
11111111
SM1-MF08-084
S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME
Q'TY
TYPE REMARK
0402 0603 2P 2P_L 4P 4P_L 4E 4E_L
40
J7265169B
PCB󰚟COVER
11111111
SM1-MF08-054R1
41
J7065981A
PROBER󰚟COVER
11111111SM1-MF08-043
42
J7066349A P-LEVER󰚟SPG󰚟0402 10000000SM1-MF08-121-1
J7066036A
P-LEVER󰚟SPRING󰚟2P
01110000SM1-MF08-121
J7066037B
P-LEVER󰚟SPRING󰚟4P
00001100SM1-MF08-122
J7066048A P-LEVER󰚟SPRING󰚟4E 00000011SM1-MF08-133
43
J7165293A
REEL󰚟COVER
11111111SM1-MF08-039
44
J7066350A
S-PAWL󰚟SPG󰚟0402
10010101SM1-MF08-123-1
J7066038A
S-PAWL󰚟SPRING
01111111SM1-MF08-123
45
J7066019A
S-PAWL󰚟SPG󰚟PIN
11111111SM1-MF08-085
46
J7065972A
SPROCKET󰚟SHAFT
11111111SM1-MF08-031
47
J7065953A
STOP󰚟PAWL
11111111SM1-MF08-010
48
J7065969A
SWING󰚟LINK󰚟SHAFT
11111111SM1-MF08-027
49
J7066026A
T-COVER
22222222
SM1-MF08-092
50
J7066008A
T󰚟LINK1󰚟SHAFT1󰚟
11111111
SM1-MF08-071
51
J7066001A
T󰚟LINK4󰚟SHAFT1󰚟
11111111
SM1-MF08-064
52
J7066022A
T󰚟LINK5󰚟SHAFT1󰚟
11111111SM1-MF08-088
53
J7065977A
TAPE󰚟GUIDE󰚟SHAFT1
11111111SM1-MF08-038
54
J7066351A
TAPE󰚟GUIDE󰚟SPG󰚟0402
10000000SM1-MF08-129-1
J7066044A
TAPE󰚟GUIDE󰚟SPRING
01111111SM1-MF08-129
55
J7066040A
TOGGLE󰚟SPRING
11111111
SM1-MF08-125
56
J7065995A
TOGGLE󰚟SPG󰚟PIN
11111111SM1-MF08-059
57
J7065994A
TOGGLE󰚟STOPPER
22222222SM1-MF08-058
58
J7066030A
TOGGLE󰚟STOPPER2
11111111
SM1-MF08-096
59
J6601136A
FLANGED󰚟BEARING
1 0 0 0 0 MF74ZZS󰚟(EZO)
60
J7065944A
V󰚟LOC󰚟PIN
11111111SM1-MF08-002
61
J7265154A VINYL󰚟ROLLER 22222222
SM1-MF08-036
