NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK

1

Sprocket󰚟Bush󰚟Ass'y󰚟-󰚟(J9065223A)

1 J7066151A SPROCKET󰚟BUSH 1 SM1-MF32-002-03

2

J7066141A SPROCKET-40 1 SM1-MF32-002-07

3

J7066142A

RATCHET-40

1 SM1-MF32-002-01

4

J7066143A

SPROCKET󰚟RIVET󰚟PIN

3 SM1-MF32-002-06

2

Sprocket󰚟Shaft󰚟72󰚟Ass'y󰚟-󰚟(J9065263A)

1

J7066297A SPROCKET󰚟SHAFT-72 1 SM1-MF72-002-02

2

J7066141A SPROCKET-40 1 SM1-MF32-002-07

3

J7066142A

RATCHET-40

1 SM1-MF32-002-01

4

J7066143A

SPROCKET󰚟RIVET󰚟PIN

3 SM1-MF32-002-06

3

Pusher󰚟Lever󰚟Rivet󰚟Ass'y󰚟-󰚟(J9065222A)

1

J7066145A

PUSHER󰚟LEVER

1 SM1-MF32-007-01

2

J7066149A PUSHER󰚟PAWL 1

SM1-MF32-007-03

3

J7066146A

PUSHER󰚟PAWL󰚟SHAFT

1

SM1-MF32-007-04

4

J7066147A

MAIN󰚟LEVER󰚟PIN

1 SM1-MF32-033-03

5

J7066150A

PUSHER󰚟PAWL󰚟SPRING

1

SM1-MF32-007-06

6

J1301023

E󰚟RING-3

1

M3

7

J7066148A

SHUTTER󰚟LEVER󰚟PIN

1

SM1-MF32-007-08

4

Pusher󰚟Lever󰚟Link󰚟Ass'y󰚟-󰚟(J9065226A)

1

J7066160A

PUSHER󰚟LINK

1

SM1-MF32-007-02

2

J7165306A

CLAMP󰚟BUSH

1

SM1-MF32-007-11

3

J7066161A

PUSHER󰚟LEVER󰚟PIN

1

SM1-MF32-031-01

5

Main󰚟Lever󰚟Ass'y󰚟-󰚟(J9065244A)

1

J7066212A

MAIN󰚟LEVER

1 SM1-MF32-033-01

2

J7066147A

MAIN󰚟LEVER󰚟PIN

1

SM1-MF32-033-03

3

J7066213A

CYLINDER󰚟BLOCK󰚟SHAFT

1 SM1-MF32-033-04

4

J7066163

SWING󰚟LEVER󰚟BUSH

1

SM1-MF32-008-02
