S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1
TAPE󰚟GUIDE󰚟ASS'Y
1
2
LOCKER󰚟ASS'Y
1
3
SPROCKET󰚟ASS'Y
1
4
PUSHER󰚟ASS'Y
1
5
CROSS󰚟LEVER󰚟ASS'Y 1
6
DRAIN󰚟GEAR󰚟ASS'Y 1
7
DRAIN󰚟ASS'Y 1
8
FORMING󰚟BRACKET󰚟ASS'Y
1
9
FORMING󰚟GEAR󰚟ASS'Y
1
10
TOGGLE󰚟ASS'Y
1
󰚟󰚟󰚟󰚟󰚟
11
REEL󰚟PLATE󰚟ASS'Y
1
12
REEL󰚟ARM󰚟ASS'Y
1
13
CYLINDER󰚟ASS'Y 1
14
J9065210A
PROBER󰚟CABLE󰚟ASS'Y󰚟
1
SM1-MF12-217
󰚟(IT󰚟EXCLUSIVE)
J9065281A
PROBER󰚟CABLE󰚟ASS'Y󰚟
1
SM1-MF12-221
󰚟(NON󰚟IT󰚟EXCLUSIVE)
15
J9065211A
INDEXING󰚟SENSOR󰚟ASS'Y
1 SM1-MF12-218
16
J7065944A
V󰚟LOC󰚟PIN
1
SM1-MF08-002
17
J7065948A
LOCATION󰚟FLANGE
1
SM1-MF08-006
18
J7065956B
LINK󰚟SHAFT󰚟COVER2
1 SM1-MF08-014
19
J7065978A
INSTALL󰚟GUIDE
1
SM1-MF08-040
20
J7065981A
PROBER󰚟COVER
1 SM1-MF08-043
21
J7065994A
TOGGLE󰚟STOPPER
2
SM1-MF08-058
22
J7066001A
T󰚟LINK4󰚟SHAFT1
1 SM1-MF08-064
23
J7066008A
T󰚟LINK1󰚟SHAFT1
1 SM1-MF08-071
24
J7066022A
T󰚟LINK5󰚟SHAFT1
1
SM1-MF08-088
25
J7066024A
COUPLER󰚟BKT1
1 SM1-MF08-090
S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
26
J7066026A
T-COVER
1 SM1-MF08-092
27
J7066030A
TOGGLE󰚟STOPPER2
1
SM1-MF08-096
28
J7066047A
FLAT󰚟HEAD󰚟CAP󰚟SCREW-H4.4
16
SM1-MF08-132
29
J9060366A
IT󰚟SLAVER󰚟BOARD󰚟
1
REV-2.0
󰚟(IT󰚟EXCLUSIVE)
J9060367A
NON󰚟IT󰚟BOARD
1
REV-1.0󰚟(NON󰚟IT󰚟EXCLUSIVE)
30
J7165295A
MAIN󰚟FRAME
1 SM1-MF16-001
31
J7066050A Y󰚟ECCENTRIC󰚟PIN 1 SM1-MF12-009-2
32
J7066051A STOP󰚟PAWL 1 SM1-MF12-010-3
33
J7066052A LIMIT󰚟SHAFT 1 SM1-MF12-017-2
34
J7066054A
SPROCKET󰚟SHAFT
1 SM1-MF16-031-2
35
J7066058A
TAPE󰚟GUIDE󰚟SHAFT
1 SM1-MF16-038
36
J7165296A
REEL󰚟COVER
1 SM1-MF12-039-3
37
J7265160A
HANDLE
1 SM1-MF12-047-3
38
J7066060A
LOCKER󰚟SHAFT
1
SM1-MF16-076
39
J7066062A SENSOR󰚟DOG 1
SM1-MF12-106-2
40
J7066063A
LEVER󰚟SHAFT1
1
SM1-MF12-108-3
41
J7066064A
CYL󰚟BKT󰚟PIN
1 SM1-MF12-109
42
J7066065A
LEVER󰚟SHAFT󰚟2
1
SM1-MF12-110-2
43
J7066066A
SPRING󰚟PIN󰚟37
1
SM1-MF12-111-2
44
J7265162A
TIE󰚟MOUNT
1
SM1-MF16-112
45
J7066068A
TAKE󰚟UP󰚟REEL󰚟SHAFT
1 SM1-MF16-115-3
46
J7066069A
TAPE󰚟SUPPORT
1 SM1-MF12-116
47
J7066070A
LOCKER󰚟SPRING
1 SM1-MF12-118-2
48
J7066071A
TAPE󰚟GUIDE󰚟SPRING
1
SM1-MF12-119-2
49
J7066072A
FEEDING󰚟SPRING
1 SM1-MF12-120-2
50
J7066073A
STOP󰚟PAWL󰚟SPRING
1 SM1-MF12-121-9
51
J7066075A
REWIND󰚟SPRING
1
SM1-MF12-123-4
S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
52
J7066040A
TOGGLE󰚟SPRING
1 SM1-MF08-125
53
J7165297A
PCB󰚟COVER
1 SM1-MF12-128-3
54
J7066076A
SPRING󰚟PIN󰚟25
4
SM1-MF12-129
55
J7066078A
DRAIN󰚟SHAFT-S
1
SM1-MF16-130-3
56
J7066080A
PCB󰚟SUPPORT
3
SM1-MF12-137
57
J7066083A
LOCKING󰚟LIMIT
1 SM1-MF12-140-2
58
J7265163A CABLE󰚟COVER 1 SM1-MF12-146
59
J7066086A LOCKER󰚟LIMIT󰚟SPRING 1 SM1-MF16-148
60
J7066313A
TOGGLE󰚟STOPPER2
1
SM1-MF12-150
61
J7265164A
VINYL󰚟ROLLER
2 SM1-MF16-036
62
J7066087A
VINYL󰚟ROLLER󰚟SHAFT
1 SM1-MF16-037-2
63
J7066088A
FORMING󰚟BKT󰚟SHAFT
1 SM1-MF12-131-3
󰚟󰚟󰚟󰚟󰚟
64
J7066089A
TAPE󰚟SUPPORT󰚟SCREW
1 TF12-N017
65
J7265131A
DAMPER
1
TF12-N226
66
J7065802A DAMPER󰚟WASHER 1
TF12-N228
67
J7065350A
LEVER󰚟SHAFT󰚟1
2
TF44-107R
68
J6049000390
ENG󰚟WASHER
1 LL-1218-01
69
J6711249A
COUPLER󰚟PLUG
1
KS-4-M5-SA34268KR
70
J6025300050
HEX󰚟NUT(STYLE󰚟2)
2
M3-STYLE󰚟2(SUS)
71
J6025400050
HEX󰚟NUT(STYLE󰚟3)
1 M4-STYLE󰚟3(SUS)
72
J1301226
C-RING(SHAFT)
1 DIA12.0(SUS)
73
J1301023
E-RING
8 DIA3.0(SUS)
74
J1301149
E-RING
4
DIA4.0(SUS)
75
J6071600050
E-RING
2 DIA6.0(SUS)
76
J6004300550
BUTTON󰚟HEAD󰚟CAP󰚟SCREW
4 M3*5(SUS)
77
J6004300650
BUTTON󰚟HEAD󰚟CAP󰚟SCREW
2
M3*6(SUS)
78
J6004301050
BUTTON󰚟HEAD󰚟CAP󰚟SCREW
2 M3*10(SUS)
