- - 36.F PI & S O T CHEC K T AB L E COMPONEN TS 7 3 1 1 1 3 1 2 1 2 1 3 1 1 1 8 2 8 9 1 0 6 5 5 5 6 5 4 1 7 1 6 1 5 1 4 1 1 9 1 2 0 2 1 2 2 2 4 2 3 2 5 2 7 2 6
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-46057 BM HOLDER 1
2 SL-6030592-TN SCREW M3 L=5 2
3 400-02267 BAD MARK SENSOR ASM 1
4 SM-6030602-TN SCREW M3X6 2
5 HD-0013100-40 SENSOR 1
6 E9638-729-000 FIBER LENS 1
7 EA-9500B01-00 CABLE BAND 4
8 EA-9500B02-00 CABLE BAND 150 8
- -
36.FPI & SOT CHECK TABLE COMPONENTS
7
3
1 1
1 3
1 2
1 2
1 3
1 1
1 8
2
8
9
1 0
6
5
5
5
6
5
4
1 7
1 6
1 5
1 4
1
1 9
1
2 0
2 1
2 2
2 4
2 3
2 5
2 7
2 6
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 SL-6061292-TN SCREW M6 L=12 6
2 401-37966 FPI_F_SUB_JX-300LED_ASM 1
3 401-10740 FPI BR B (1)
4 401-10741 FPI COVER B (1)
5 SM-6030402-TN SCREW M3X4 (9)
6 WP-0320501-SC WASHER M3 (4)
7 E6025-729-0A0 FPI COVER U20 ASM (1)
8 E6025-729-000 FPI COVER U20 (1)
9 E6028-729-000 FPI PLATE U20 (1)
10 SM-6030402-TN SCREW M3X4 (2)
11 400-94870 HARNESS CLAMP A (2)
12 SM-6030402-TN SCREW M3X4 (2)
13 WP-0320501-SC WASHER M3 (2)
14 E8626-729-0A0 FPI LED BOARD ASM. (4)
15 SM-5030801-SC SCREW M3X0.5 L=8 (8)
16 E2143-715-000 TIMER SPACER A (8)
17 E4901-760-000 POLY SLIDER THRUST WASHER (8)
18 E6033-729-000 FPI INSULATION SHEET (0.2)
19 401-35893 FPI_BR_L 1
20 401-35894 FPI_BR_R 1
21 400-45984 SOT CHECK BASE 1
22 SM-1030601-SC SCREW M3 L=6 2
23 PJ-3010405-05 HALF UNION 1
24 PJ-3050400-01 TEE 1
25 BT-0400251-EA TUBE HOSE, BLUE 0.2
26 SL-6061492-TN BOLT 2
27 401-35895 SOT_CHECK_BASE_BR 1
