Chapter 1 AOI Standard Project Creation
TR7500 USER MANUAL
3
(3) Input CAD file
Browse CAD
file path
Selecting AOI
translator
Types of different
Translator for varies
SMT machine vendor

Chapter 1 AOI Standard Project Creation
TR7500 USER MANUAL
4
(4) Unit defines from CAD file.
(5) Start translation.
Choosing a CAD
file and open it
Choosing unit depend
on CAD file

Chapter 1 AOI Standard Project Creation
TR7500 USER MANUAL
5
(6) Translator successful Message.
(7) Quit Translator
Start translate CAD
file into AOI file
