Sitest Overview SITEST Buttons in the Main Menu and Submenus S tudent Guide SIPLACE D4 (FSE) Sitest EN 09/2006 286
Sitest
Buttons in the Main Menu and Submenus Overview SITEST
Student Guide SIPLACE D4 (FSE)
EN 09/2006 Sitest
285
12.1.4 Buttons in the Main Menu and Submenus
Sitest
Overview SITEST Buttons in the Main Menu and Submenus
Student Guide SIPLACE D4 (FSE)
Sitest EN 09/2006
286
Sitest
Buttons in the Main Menu and Submenus Calibration
Student Guide SIPLACE D4 (FSE)
EN 09/2006 Sitest
287
12.2 Calibration
Equipment and Testing Tools
SITEST, version 602.xx or higher
Calibration device
Version II transparent S/F/HS --> 00316308-03
Version III not transparent HF/X/D machines with C&P6/12 and Twin Head --> 03010565-01
Version SST 23 X machine C&P20 --> 03034148-01
Nozzles, type 1235, 956, 517, 518, nozzle for ZPC D-axis TH 03008862-03
Setting gauge for S tables
PCB for calibration of conveyor width
DANGER: RISK OF INJURY!
The gantry may move during some of the following procedures.
Therefore, before you begin with any of these procedures make sure that you
and everyone else stay physically clear of the travel range of the gantries.
X Also, sure, that no objects are in the way.
NOTE:
Before you begin with the calibration, you must reference the heads and the
gantries.
During calibration, unused gantries will automatically be moved to their parking
position.
To completely calibrate the machine, go to
Calibrate machine...
and select
the
Calibrating the entire machine
menu. This provides all the required
calibration functions.
