PCB Libraries Presents:
What is New in IPC-7351C
• Ball Grid Array
• Column Grid Array
• Land Grid Array
• Dual Flat No-lead
• Thermal Pads
Lead Styles Exempt from Rounded Rectangle Pads
Under Body Terminal Leads where a
Periphery Pad is required:
PCB Libraries Presents:
What is New in IPC-7351C
• Silkscreen Outline and Polarity Marking
• Assembly Outline and Polarity Marking
• Courtyard Outline
• Land Pattern Origin Marker
• Component Outline
• Terminal Lead Outline
Guidelines for Drafting Items
PCB Libraries Presents:
What is New in IPC-7351C
1. No silkscreen outline under the component body; these get covered up
during assembly and don’t provide any useful purpose (waste of good ink)
2. Silkscreen outlines visible after assembly process and provide a functional
use as alignment marking for assembly registration accuracy
3. Silkscreen outlines should be inside placement courtyard
4. Silkscreen outlines should be mapped to the Maximum Component Body
with one exception, the Silkscreen to Pad spacing rule “overrides” the
Component Body Mapping
5. Silkscreen outlines should map the component body and not go around
pads. Excess silkscreen outlines should be avoided to make room for ref
des locations. Silkscreen outlines should perform a “hatch” outline along
the component package body.
6. Pin 1 is identified by extending the silkscreen along Pin 1 length of pads
when component leads extend outward. Bottom only terminals Pin 1 is
identified by a missing line.
Silkscreen Outline Guidelines
