Premium Dispensing Tips
TT Dispensing Tips
The tapered tip prevents blockage and increase
the flow of high viscosity material. Standard tips
are molded in high density polyethylene with UV
light block additive. Rigid tips are molded in
polypropylene with opaque color. Sold in bulk
and packs of 50.
Gauge Color Standard TT Tips Rigid TT Tips
14 Olive TT14-DHUV-1000 TT14-RIGID-1000
16 Grey TT16-DHUV-1000 TT16-RIGID-1000
18 Green TT18-DHUV-1000 TT18-RIGID-1000
20 Pink TT20-DHUV-1000 TT20-RIGID-1000
22 Blue TT22-DHUV-1000 TT22-RIGID-1000
25 Red TT25-DHUV-1000 TT25-RIGID-1000
27 Clear TT27-DHUV-1000 TT27-RIGID-1000
BT Series
Use these double helix Brush Tips for “spread”
applications such as glues and other materials.
Soft brush is made of Red Sable. Stiff brush is
made of Nylon. Sold in packs of 12.
Gauge Soft Bristle Stiff Bristle
16 BT16-SOFTPK BT16-STIFFPK
18 BT18-SOFTPK BT18-STIFFPK
22 BT22-SOFTPK BT22-STIFFPK
Dispensing Tip Kit
Decide for yourself which tip to use. This kit contains a variety of
the most popular 700 Series tips to let you test different tips to find
the ones that fit your needs.
Part No. Description
TN00DKIT Dispensing Tip Kit
TS-P Plastic Dispensing Tips
Flexible tips allow access to hard to reach areas
and allow you to “customize” the length. Ideal
for CA applications. 1
1/2
" length. Sold in bulk and
packs of 50. Made from polypropylene.
Gauge Color TS-P Dispensing Tips
15 Grey TS15P-1-1/2-500
16 Brown TS16P-1-1/2-500
18 Pink TS18P-1-1/2-500
20 Yellow TS20P-1-1/2-500
22 Black TS22P-1-1/2-500
25 Red TS25P-1-1/2-500
8
700 & 400 Series Dispensing Components
400 Series Disposable Dispensing Components
The 400 Series disposable syringes and components are available in a variety of styles to meet a wide range of applications.
Sold in bulk packages only.
Syringe Barrels
Barrels are molded from polypropylene.
Standard style is Luer lock. Luer slip and
taper tip styles are also available,
however minimum quantity, lead time
and pricing considerations apply. In
Natural color only (for black and amber
refer to page 4).
Part No. Description
F401L-1 400 Syringe Barrel 1cc Luer Slip
403LL-1 400 Syringe Barrel 3cc Luer Lock
406LL-1 400 Syringe Barrel 6cc Luer Lock
410LL-1 400 Syringe Barrel 10cc Luer Lock
435LL-1 400 Syringe Barrel 35cc Luer Lock
460LL-1 400 Syringe Barrel 60cc Luer Lock
Plungers
Part No. Description
403L-4 3cc Plunger
406L-4 6cc Plunger
410L-4 10cc Plunger
435L-4 35cc Plunger
460L-4 60cc Plunger
Stoppers
Rubber stoppers listed are not lubricated. For
lubricated stoppers add -LUB to the part number.
Part No. Description
401L-2 1cc Rubber Stopper, Manual
403L-2 3cc Rubber Stopper, Manual
406L-2 6cc Rubber Stopper, Manual
410L-2 10cc Rubber Stopper, Manual
435L-2 35cc Rubber Stopper, Manual
403L-7 3cc Plastic Wiper Stopper, Manual
406L-7 6cc Plastic Wiper Stopper, Manual
410L-7 10cc Plastic Wiper Stopper, Manual
435L-7 35cc Plastic Wiper Stopper, Manual
401L-2 1cc Rubber Stopper, Air Powered
403L-2 3cc Rubber Stopper, Air Powered
406L-8 6cc Rubber Stopper, Air Powered
410L-8 10cc Rubber Stopper, Air Powered
435L-8 35cc Rubber Stopper, Air Powered
403L-9 3cc Plastic Wiper Stopper, Air Powered
406L-9 6cc Plastic Wiper Stopper, Air Powered
410L-9 10cc Plastic Wiper Stopper, Air Powered
435L-9 35cc Plastic Wiper Stopper, Air Powered
460L-9 60cc Plastic Wiper Stopper, Air Powered
Manual Plungers and Pistons
for 700 Series Syringe Barrels
The new manual syringe assemblies provide simple and quick
dispensing solutions without the need for compressed air. Molded
from Polypropylene resin, manual plungers are compatible with a
wide range of dispensing fluids. Pistons are made from thermoplastic
rubber and are available dry or with lubrication. Sold in packs of 50.
Part No. Description
7
030004PPK 700 Manual Plunger, 3cc
7
030002MPK 700 Manual Piston Rubber, 3cc
7030002M-LUBPK 700 Manual Piston Rubber, Lub, 3cc
7050004PPK 700 Manual Plunger, 5cc
7050002MPK 700 Manual Piston Rubber, 5cc
7
050002M-LUBPK 700 Manual Piston Rubber,Lub, 5cc
7
100004PPK 700 Manual Plunger, 10cc
7100002MPK 700 Manual Piston Rubber, 10cc
7100002M-LUBPK 700 Manual Piston Rubber, Lub, 10cc
7300004PPK 700 Manual Plunger, 30cc
7300002MPK 700 Manual Piston Rubber, 30cc
7300002M-LUBPK 700 Manual Piston Rubber, Lub, 30cc
.
See pages 4 and 5 for syringes and tip caps
9
400 Series Manual Syringe Components
PLUNGER
SYRINGE BARREL
STOPPER
400 Series Disposable Dispensing Components
The 400 Series disposable syringes and components are available in a variety of styles to meet a wide range of applications.
Sold in bulk packages only.
Tip Caps
P
art No. Description
15LL Luer Lock Tip Cap
15LL-B Black Luer Lock Tip Cap
End Caps
Part No. Description
T
S5 6cc End Cap
T
S7 10cc End Cap
Receiver Head Assemblies
The connecting link between time/pressure controllers and syringe
assemblies, Receiver Head Assemblies provide a safe connection
between receiver head and syringe barrel for accident proof dispensing.
Receiver Head Assemblies come with no tubing (-R), 3 feet of tubing (-3)
or 6 feet of tubing (-6).
400 Series Receiver Head Assemblies
Part No. Size
9
00-250-3, -6 or -R 1cc
9
00-350-3, -6 or -R 3cc
900-550-3, -6 or -R 6cc
900-650-3, -6 or -R 10cc
9
00-950-3, -6 or -R 35cc
900-1150-3, -6 or -R 60cc
400 Series Manual Syringe Components
Syringe barrels and plungers are molded from polypropylene; stoppers are molded from
polyethylene (-7) or thermoplastic rubber (-2). Plunger locks to the stopper for smooth,
controlled manual dispensing. Use of a tip cap will seal the delivery end of the syringe
barrel when not dispensing.
Manual Syringes with Rubber Stoppers
Barrels and plungers are molded from polypropylene. Stoppers are molded from
thermoplastic rubber.
Size Syringe Stopper Plunger
3cc 403LL-1 403L-2 403L-4
6cc 406LL-1 406L-2 406L-4
10cc 410LL-1 410L-2 410L-4
35cc 435LL-1 435L-2 435L-4
Manual Syringes with Plastic Stoppers
Barrels and plungers are molded from polypropylene. Stoppers are molded from
polyethylene for better chemical compatibility.
Size Syringe Stopper Plunger
3cc 403LL-1 403L-7 403L-4
6cc 406LL-1 406L-7 406L-4
10cc 410LL-1 410L-7 410L-4
35cc 435LL-1 435L-7 435L-4
