Base
Page 24 / 26 24.11.2021
Pos. Item no. Description Part marking
91 00306732-01 PUSH BUTTON INNER HALF PS-1,
10.3MM
93 00330667S02 SUPPORTING RAIL FOR
PROTECTION
94 00845059-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 20-8.8
97 00349458-01 ON-OFF PUSHBUTTON 3SB3
WT(I)/BL(0)
SPARE PART
99 00334073-01 MUSHROOM PUSHBUTTON 3SB3
RED 40MM
SPARE PART
100 00335307-02 CABLE HS50: ON-KEY/COVER PCB
IN/OUT
101 00305521-01 CROSS RECESSED RAISED CHEESE
HEAD SCREW
102 00335306-02 CABLE HS50: START
/STOP/EMERGENCY-STOP
SPARE PART
00335624-01 SINGLE PARTS SAFETY
COVER/FRAME HS50
103 00330680-01 SAFETY COVER-ANGLE/FRAME HS50 SPARE PART
104 00330682-01 SAFETY COVER-RAIL/FRAME HS50 SPARE PART
105 00330683-01 SAFETY COVER-PLATE/FRAME HS50
106 00845026-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 12-8.8
107 00048335-01 DIN 9021 - 4.3 - 140 HV - ST DISK
108 00095551-01 HEXAGON NUT
109 00308083-01 HEXAGON SOCKET HEAD CAP
SCREW
110 00331444-01 FLAP HINGE/FRAME HS50 Spare Part
111 00330650-01 HINGED COVER FOR
EXTENSION/FRAME HS50
SPARE PART
112 00304577-01 FLEXIBLE ACTUATOR AZ 15/16 SPARE PART
113 00304188-01 MOUNTING FOOT 22*4,3*14 STANDARD PARTS
114 00845025-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 10-8.8
115 00309802-01 CROSS RECESSED RAISED CHEESE
HEAD SCREW
116 00335966-03 TAPE MEASURE Y-AXIS SPARE PART
117 00343053-01 CABLE CLIP
118 00095473-01 PLAIN WASHER A 5.3-140HV-ST
119 00845042-01 HEXAGON SOCKET HEAD CAP
Base
Page 25 / 26 24.11.2021
Pos. Item no. Description Part marking
SCREW M5 X 10-8.8
120 00331999-02 WASTE TAPE CHUTE SPARE PART
121 00334099-01 ASSEMBLY STUD BUFFER Spare Part
122 00336255-01 COMPONENTS CARRIAGE BUFFER
MOUNT
123 00304704-03 SLEEVE SPARE PART
124 00201033-01 PLASTIC SPRING 8,5*20*40 (90
SHORE) RED
SPARE PART
125 00845060-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 25-8.8
126 00845078-01 DIN912-M8 X 30-8.8
127 00048338-01 WASHER
00330493-02 ASSEMBLY SUPPORTING RAIL
129 00337802-02 SWITCH MOUNT RIGHT
130 00337803-02 SWITCH MOUNT LEFT
131 00335263-02 SWITCH FOR COVER SECTOR 1 TO 4 SPARE PART
132 00095474-01 DISC 6,4 DIN125-A Spare
133 00095046-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 14-8.8
134 00845044-01 HEXAGON SOCKET HEAD CAP
SCREW M5 X 16-8.8
135 00095473-01 PLAIN WASHER A 5.3-140HV-ST
136 00095565-01 HEXAGON NUT
137 00333837-02 GUIDE RAIL UFB *
138 00845025-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 10-8.8
139 03069810S01 LINEAR MOTOR SECONDARY UNIT *
140 03069811S01 LINEAR MOTOR SECONDARY UNIT *
141 00845057-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 12-8.8
142 00304632-05 CENTERING BOLT SPARE PART
145 00345187-01 GUIDE RAIL TKVD 25 G3 HJ/1900
146 00313994-01 HEXAGON SOCKET HEAD CAP
SCREW
147 00347404-02 COMPONENT REJECT BOX SPARE PART
148 00344686-02 ECCENTRIC DISC SPARE PART
149 00095012-01 DIN912-M3 X 18-8.8
150 00350332-01 EDGE PROTECTION
