2 Spare parts overview 2.4 List of all spare parts 18 Service Manual SIPLACE Head Care Station II 11/2019
2 Spare parts overview
2.4 List of all spare parts
Service Manual SIPLACE Head Care Station II 11/2019 17
2.4 List of all spare parts
03152714-xx Safety switch door HCS2.3
03067289-xx VISION BOARD Spread Spectrum HCU cpl.
03050555-xx Vision Hotlink Adapter VHA
03090990-xx MHCU complete compatible
03149124-xx Headcare interface HCS II v2.3
03055072-xx Modul Head Interface C700B
03008825-xx Assembly PCB digital 28
03087843-xx Board Adapter-LP CPP/C&P20-HCS II
03087842-xx Board Adapter-LP C700B-HCSII
03085198-xx Board Adapter Headinteface C700B
03085251-xx LabJack UE9
03158917‑xx PCB-base adapter-C&P-HCS2.3
03158916‑xx PCB-base adapter-Twin-HCS2.3
03087844-xx Board Adapter-LP Twin-HCSII
03079126-xx AC/DC converter FlatPAC 150VDC 400W
03087898-xx AC/DC converter QS10.241 24VDC 10A 240W
03147077-xx AC/DC converter FlatPAC 2 x 40VDC 400W
03120423-xx BoxPC ABP402-A CPU1020E 2xPCI SSD (iBase)
03079973-xx CAN card COM168V2-PCI
03052135-xx Hotlink Interface PCI-A24-K01
03090149-xx PCB Power adjust HCS II cpl.
03148066-xx Cable: Hotlink
03152929-xx Cable connection cable HCS2.3
03159108-xx CAN-BUS: HCS2.3
00375711-xx Connection cable for cold equipment
03148065-xx Cable: USB IO Modul LabJack
03148067-xx Cable: PC GigE
03065971-xx Cable set CPP / B series
03065867-xx Flat cable set C&P20 / B series
03104448-xx VTS board head camera GigE
03152714-xx Safety switch door HCS2.3
03037590-xx Fuse clamp max. 10A type 281-611
03010624-xx Feinsicherung 5x20 / T 1,0A / keramik
03133256-xx Fuse 5x20mm T 6,3A 400VDC
03079075-xx Compressed air filter
Filter element AF40P-060S for compressed air
03003717-xx Cooling air filter element
2 Spare parts overview
2.4 List of all spare parts
18 Service Manual SIPLACE Head Care Station II 11/2019
3 Preparatory work...
3.1 Turn off and disconnect the HCS II
Service Manual SIPLACE Head Care Station II 11/2019 19
3 Preparatory work...
DANGER
Observe safety instructions!
► Please observe the safety instructions in this Service Manual and in the HCSII User
Manual for all work!
NOTICE
Observe the detailed circuit diagrams!
► For more detailed information refer to the circuit diagrams folder of the HCSII.
●
Detailed circuit diagrams folder for HCSII [DEEN:00198762‑xx]
3.1 Turn off and disconnect the HCS II
DANGER
Nonobservance may cause injury to personnel and damage to the HCS II!
► Before performing any service work on the HCS II, the following steps must be per-
form.
► End all verification operations at the HCS II.
► Close the SIPLACE Test Bench software.
► Shut down the Windows operating system correctly, otherwise problems may occur when
restarting or data may be lost.
► Switch off the HCS II at the main switch.
► Disconnect the HCS II from the main power supply.
► Disconnect the HCS II from the compressed air supply.
3.2 Equipment and tools
Equipment and tools needed to prepare the HCS II Head Unit for service work:
00353832‑xx Allen key set 2 mm, 2.5 mm
00376516-xx Socket wrench set 7 mm
00096290-xx Spanner wrench set 7 mm
00319064-xx Screwdriver Size 1
00318673-xx Side cutter electronic size 110
00096487-xx POINT PLIERS 140mm OVAL
00308458-xx Cable ties B=2.5mm, L=102mm Panduit
