SIPLACE 80S-20/F4 User Manual 11 Station extensions /Hardware

Software version SR.407.xx 01/2001 US Edition 11.2 Component barcode

471

11.2 Component barcode

11.2.1 General

The placement machine allows the track assignment to be checked using a barcode reader, and

the component data to be read from the component reels. 11

Fig. 11.2 - 1 Component barcode reader

(1) Barcode reader

Track allocation 11

There are four-digit barcode strips on the lateral protective covers in order to identify the track al-

location. The first digit is used to identify the component feeder table (1 or 2). The other three digits

indicate the track number. Return barcodes are provided at both ends of the barcode strip. The

barcode strips are numbered consecutively in intervals of two (1, 3, 5, 7, …), and each strip is used

for 2 tracks (barcode 1 = track 1 and 2). 11

11 Station extensions /Hardware SIPLACE 80S-20/F4 User Manual

11.2 Component barcode Software version SR.407.xx 01/2001 US Edition

472

Components 11

Data is read from the component reels in order to compare the stock of components with the quan-

tity required in the set-up file (refill check), for example. 11

An audible signal is given to confirm that each dataset has been read successfully. 11

PLEASE NOTE 11

The component barcode reader option must be configured on the line computer.

Barcodes that start with number 1 or 2, and are less than 5 characters long, are interpreted as

track barcodes. All other barcodes (that do not start with number 1 or 2, and are more than 5 char-

acters long) are interpreted as component barcodes. 11

11.2.2 Notes on operation

– The barcode reader must be connected.

– The barcode must be entered on the line computer for every component.

Å To do this, select the “Set-up check with barcode” function from the Machine options menu.

Fig. 11.2 - 2 Set-up check with barcode

SIPLACE 80S-20/F4 User Manual 11 Station extensions /Hardware

Software version SR.407.xx 01/2001 US Edition 11.2 Component barcode

473

PLEASE NOTE: 11

If one of the barcode digits is assigned a wild card (star *), this digit will not be evaluated. This filter

is used to suppress certain data in the barcode, such as the date or company name. 11

– Once you have activated the component barcode on the line computer, and selected “Set-up

check with barcode” from the machine options at the station, “Refill location” and “Refill track

with barcode” functions can no longer be used manually.

– A manual “Refill” can still be used on tracks with components without barcodes, even if the refill

check is switched on.

Procedure if the barcode cannot be read: 11

Å Switch off the refill check in the machine options.

Å Enter the barcode manually.

11.2.3 Operation

Å Select the “Empty tracks” view from the Set-up menu.

Å Use the barcode reader to read the desired track barcode.

If the track is present in the set-up, and the component has a barcode, the “Set-up check with

barcode” dialog will appear, specifying the track concerned.

PLEASE NOTE 11

You can open the dialog by clicking on the desired track or by clicking on the “Set-up check

with barcode” button. 11

Once the return barcode has been compared and read successfully, the track can be refilled. 11
