Monitor / Conv.Muzzle / Base
Cover
LF4-1612
2-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
LC3-M13AR-00
MG. CATCH
4
2
LC3-M65D1-00
SEAL,CHARGE
3
3
LE6-M1102-04
COVER,BASE
4
4
LE6-M1103-00
COVER,STAY1
4
5
LE6-M1104-00
COVER,STAY2
4
6
LE6-M1105-00
COVER,STAY3
8
7
LE6-M1106-00
SCREW,TORX BUTTON
8
8
LE6-M1110-00
COVER,BASE ASSY.
4
9
LE6-M1302-E1
PANEL,2
1
10
LE6-M1309-00
PANEL 9
1
11
LE6-M1311-E0
BASE,MONITOR
1
12
LE6-M1312-E1
BRKT,MONITOR
1
13
LE6-M1313-E0
COVER,ARM
1
14
LE6-M134B-E1
BRACKET,MG 3
4
15
LE7-M131L-11
BALANCER
1
16
LE7-M132M-00
GOM
1
17
LE8-M1351-00
MUZZLE 1
2
18
LE8-M1352-00
MUZZLE 2
2
19
LF3-M1303-01
PANEL,3
1
20
LF3-M1304-00
PANEL, 4
1
21
LF3-M1305-00
PANEL, 5
1
22
LF3-M1372-00
GOM
1
23
LF3-M1372-10
GOM
2
24
LG0-M110P-01
PAD, MOUSE
1
25
90990-12J001
SCREW, BIN. HEAD W/W
22
26
90990-46J006
BOLT, THIN HEAD
1
27
90990-46J015
BOLT, THIN HEAD
12
28
91312-03005
BOLT HEX,SOCKET HEAD
16
29
91312-03006
BOLT HEX,SOCKET HEAD
8
30
91312-04008
BOLT HEX,SOCKET HEAD
9
31
91312-04012
BOLT HEX,SOCKET HEAD
2
32
91312-05010
BOLT HEX,SOCKET HEAD
2
33
92902-03200
WASHER,PLAIN
8
34
92902-04200
WASHER,PLAIN
8
35
98902-04012
SCREW BINDING HEAD
4
36
98902-05010
SCREW BINDING HEAD
16
