Box,ELE. Assy
Head
LF4-1612
5-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
LF3-M65E9-00
X SENSOR ASSY
1
2
LE4-M6516-00
SERVO AMP
1
3
LF3-M65A4-00
DC FAN
1
4
LE6-M6551-00
SERVO AMP
1
5
LF1-M71H6-01
XIO.HI BOARD ASSY
1
6
LF3-M7181-00
BOX,AMP
1
7
LF3-M7182-00
COVER,BOX
1
8
LF3-M7183-00
PLATE,FAN
1
9
LF3-M7185-00
BRKT.BOARD
1
10
LF3-M7187-00
STAY,DUCT
1
11
LF3-M7188-00
BRKT.AMP
1
12
LF3-M7189-00
STAY,CABLE 1
1
13
LF3-M718A-00
STAY,CABLE 2
1
14
LF3-M718C-00
BRKT.BOX 1
1
15
LF3-M718E-00
BRKT.BOX 2
1
16
LF3-M718F-00
CLAMP,CABLE X
1
17
LF3-M718G-00
PLATE,AMP
1
18
LG0-M22H3-00
GUARD,FINGER
1
19
$UYD10-8
JOINT
1
20
91317-03005
BOLT HEX,SOCKET HEAD
20
21
91317-03006
BOLT HEX,SOCKET HEAD
40
22
91317-03008
BOLT HEX,SOCKET HEAD
6
23
91317-04008
BOLT HEX,SOCKET HEAD
10
24
91317-04035
BOLT HEX,SOCKET HEAD
4
25
91317-05010
BOLT HEX,SOCKET HEAD
4
26
92907-03200
WASHER,PLAIN
2
27
92907-04200
WASHER,PLAIN
4
28
97602-03306
SCREW PAN HEAD W/WASHER
6
16
16
17
16
15
3
3
7
18
10
1
14
19
16
19
14
12
1
18
6
8
12
4
5
9
15
14
14
14
14
14
14
11
2
13
13
16
16
17
16
15
3
3
7
18
10
1
14
19
16
19
14
12
1
18
6
8
12
4
5
9
15
14
14
14
14
14
14
11
2
13
13
Cover / Valve (OLD)
Head
LF4-1612
5-3
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
LE6-M712A-00
PIN,DOWEL
12
2
LF1-M7105-00
BRKT,SOL. CABLE
1
3
LF1-M710C-00
KNOCK PIN
4
4
LF1-M712B-00
TUBE
12
5
LF1-M717A-10
SOL.VALVE ASSY.
1
6
LF1-M71A8-00
VALVE ASSY.
1
7
LF3-M7101-00
PLATE,Z
1
8
LF3-M710D-00
BRACKET,HEAD
1
9
LF3-M7162-00
SUPPORT BRKT,L
1
10
LF3-M7164-00
SUPPORT BRKT,R
1
11
LF3-M7165-00
COVER,F
1
12
$USD8-6
JOINT
2
13
91312-03020
BOLT HEX,SOCKET HEAD
4
14
91317-03006
BOLT HEX,SOCKET HEAD
16
15
91317-04006
BOLT HEX,SOCKET HEAD
4
16
91317-04010
BOLT HEX,SOCKET HEAD
24
17
91317-05014
BOLT HEX,SOCKET HEAD
2
18
91317-08025
BOLT HEX,SOCKET HEAD
4
19
92907-08200
WASHER,PLAIN
4
15
11
13
13
8
4
14
3
11
11
11
15
14
6
2
1
10
10
11
7
11
9
11
12
11
5
12
15
11
13
13
8
4
14
3
11
11
11
15
14
6
2
1
10
10
11
7
11
9
11
12
11
5
12
Cover / Valve (NEW)
Head
LF4-1708
5-4
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
LF1-M712B-00
TUBE
12
182mm
2
LF1-M717A-10
SOL.VALVE ASSY.
1
3
LF1-M71A8-00
VALVE ASSY.
12
4
LF3-M7101-10
BASE,HEAD
1
5
LF3-M7105-00
BRKT,SOL. CABLE
1
6
LF3-M710D-01
BRACKET,HEAD
1
7
LF3-M7162-01
SUPPORT BRKT,L
1
8
LF3-M7164-01
SUPPORT BRKT,R
1
9
LF3-M7165-10
COVER,F
1
10
$USD8-6
JOINT
2
11
91312-03006
BOLT HEX,SOCKET HEAD
18
12
91312-03012
BOLT HEX,SOCKET HEAD
4
13
91317-04006
BOLT HEX,SOCKET HEAD
4
14
91317-08025
BOLT HEX,SOCKET HEAD
4
15
92907-08200
WASHER,PLAIN
4
