S20_LF4_pl - 第37页
5 27 40 13 14 33 8 35 20 42 15 16 10 4 12 13 14 6 11 41 7 15 44 3 36 35 35 31 21 2 17 26 39 25 32 30 35 43 1 18 37 24 33 28 23 34 22 9 36 31 2 19 26 39 29 43 38 5 27 40 13 14 33 8 35 20 42 15 16 10 4 12 13 14 6 11 41 7 1…
15
16
28
19
25
25
18
20
19
15
15
15
15
15
17
26
26
12
14
22
24
17
24
27
10
17
8
13
1
27
6
11
28
21
4
9
2
24
7
24
23
5
23
16
3
15
16
28
19
25
25
18
20
19
15
15
15
15
15
17
26
26
12
14
22
24
17
24
27
10
17
8
13
1
27
6
11
28
21
4
9
2
24
7
24
23
5
23
16
3
Z-axis Sub Assy (NEW)
Head
LF4-1708
5-8
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
LC6-M770A-00
NOZZLE P005
1
2
LF3-M65M3-10
Z1 MOTOR ASSY
1
3
LF3-M65M3-20
Z2 MOTOR ASSY
1
4
LF3-M65M3-30
Z3 MOTOR ASSY
1
5
LF3-M65M3-40
Z4 MOTOR ASSY
1
6
LF3-M65M3-50
Z5 MOTOR ASSY
1
7
LF3-M65M3-60
Z6 MOTOR ASSY
1
8
LF3-M65M3-70
Z7 MOTOR ASSY
1
9
LF3-M65M3-80
Z8 MOTOR ASSY
1
10
LF3-M65M3-90
Z9 MOTOR ASSY
1
11
LF3-M65M3-A0
Z10 MOTOR ASSY
1
12
LF3-M65M3-B0
Z11 MOTOR ASSY
1
13
LF3-M65M3-C0
Z12 MOTOR ASSY
1
14
LF3-M7102-00
PLATE,MOTOR Z
1
15
LF3-M7120-00
Z AXIS ASSY.
6
16
LF3-M712K-00
MAGNET
12
17
LF3-M7130-00
SHAFT,Z ASSY
12
18
LF3-M7191-10
BRKT,Z-AXIS BOTTOM
1
19
LF3-M7192-01
BRKT,Z-AXIS
2
20
LF3-M71AT-00
COVER,B.S.
1
21
LF3-M71E0-00
SLIDER,Z UNIT 1
6
22
LF3-M71F0-00
SLIDER,Z UNIT 2
6
23
90167-02JA06
SCREW, FLAT HEAD
12
24
91312-03004
BOLT HEX,SOCKET HEAD
8
25
91312-03012
BOLT HEX,SOCKET HEAD
19
26
91312-03016
BOLT HEX,SOCKET HEAD
24
27
91312-04014
BOLT HEX,SOCKET HEAD
5
28
99480-03008
PIN,PARALLEL
8
5
27
40
13
14
33
8
35
20
42
15
16
10
4
12
13
14
6
11
41
7
15
44
3
36
35
35
31
21
2
17
26
39
25
32
30
35
43
1
18
37
24
33
28
23
34
22
9
36
31
2
19
26
39
29
43
38
5
27
40
13
14
33
8
35
20
42
15
16
10
4
12
13
14
6
11
41
7
15
44
3
36
35
35
31
21
2
17
26
39
25
32
30
35
43
1
18
37
24
33
28
23
34
22
9
36
31
2
19
26
39
29
43
38
Z-axis (OLD)
Head
LF4-1612
5-9
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLH-M7C2A-00
BEARING
2
2
LC1-M71AG-00
HOSE NIPPLE(BL)
2
3
LC1-M71GN-30
SCREW,PAN HEAD
4
4
LC6-M714R-00
LEAF,SPRING 1
2
5
LC6-M714S-00
LEAF,SPRING 2
2
6
LC6-M714T-00
LEAF,SPRING 3
2
7
LC6-M714U-00
LEAF,SPRING 4
2
8
LC6-M71AY-00
PIN,PARALLEL
2
9
LE6-M7130-00
HOLDER NOZZLE ASSY
2
10
LE6-M714M-00
HOLDER,NOZZLE
2
11
LE6-M714N-01
COLLAR,SEAL
2
12
LE6-M716E-01
FLANGE
2
13
LE6-M716J-00
PLATE,JOINT 2
4
14
LE6-M716K-00
PLATE,JOINT 1
4
15
LE6-M71A4-00
BRG.
6
16
LE6-M71F2-00
NUT,HEXAGON(M1.6)
2
17
LE6-M947A-01
BRG
2
18
LF1-M7121-00
FRAME,Z
1
19
LF1-M7122-11
HOLDER,TR.
1
20
LF1-M7122-20
HOLDER,TL.
1
21
LF1-M7124-20
PLATE,BRG. 2
2
22
LF1-M712F-00
COUPLING
2
23
LF1-M712G-00
PLATE,BRG. 1
2
24
LF1-M712H-00
COLLAR,BRG.
2
25
LF1-M712K-00
MAGNET
2
26
LF1-M712L-00
PLATE,MAGNET
2
27
LF1-M712N-00
SHIM,BRG.(T0.01)
2
28
LF1-M712Y-00
LOCK NUT
2
29
LF1-M717L-00
BLOCK,BRG. R.
1
30
LF1-M717L-10
BLOCK,BRG. L.
1
31
LF1-M717M-00
HOUSING,NOZLLE
2
32
LF1-M71AB-00
BALL SCREW
2
33
LF1-M71AC-00
LM GUIDE
2
34
90112-02J005
BOLT HEX,SOCKET HEAD
8
35
90115-2AJ006
BOLT, HEX. SOCKET HEAD
26
36
90115-2AJ010
BOLT, HEX. SOCKET HEAD
8
37
90115-2AJ012
BOLT, HEX. SOCKET HEAD
2
38
90115-2AJ016
BOLT, HEX. SOCKET HEAD
2
39
90167-02JA06
SCREW, FLAT HEAD
4
40
90440-10J023
CIRCLIP
2
41
90990-01J101
BOLT HEX,SOCKET HEAD
2
42
90990-22J010
PACKING
4
43
92990-03600
WASHER,PLAIN
4
44
95602-04100
NUT,S/L
2
26
37
32
33
29
16
23
28
11
9
35
8
6
2
25
38
10
8
3
20
31
9
4
18
34
5
22
29
1
24
17
7
15
19
29
29
12
21
27
13
37
24
30
12
39
7
14
36
29
19
29
21
30
26
37
32
33
29
16
23
28
11
9
35
8
6
2
25
38
10
8
3
20
31
9
4
18
34
5
22
29
1
24
17
7
15
19
29
29
12
21
27
13
37
24
30
12
39
7
14
36
29
19
29
21
30
Z-axis (NEW)
Head
LF4-1708
5-10
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
LC1-M71GN-30
SCREW,PAN HEAD
4
2
LC6-M714R-00
LEAF,SPRING 1
2
3
LC6-M714S-00
LEAF,SPRING 2
2
4
LC6-M714T-00
LEAF,SPRING 3
2
5
LC6-M714U-00
LEAF,SPRING 4
2
6
LC6-M71AY-00
PIN,PARALLEL
2
7
LE2-M90D2-01
JOINT
2
8
LE6-M716J-00
PLATE,JOINT 2
4
9
LE6-M716K-00
PLATE,JOINT 1
4
10
LE6-M71A4-00
BRG.
6
11
LE6-M71F2-00
NUT,HEXAGON(M1.6)
2
12
LF1-M71AC-00
LM GUIDE
2
13
LF3-M7121-00
FRAME,Z
1
14
LF3-M7122-00
HOLDER,TR
1
15
LF3-M7123-00
HOLDER,TL
1
16
LF3-M7124-00
PLATE,BRG.
2
17
LF3-M712F-00
COUPLING,Z AXIS
2
18
LF3-M712G-00
PLATE,BRG. 1
2
19
LF3-M712L-00
PLATE,MAGNET
2
20
LF3-M712Y-00
NUT,LOCK
2
21
LF3-M717L-00
BLOCK,BRG.
2
22
LF3-M717M-00
HOUSING,NOZZLE
2
23
LF3-M71AB-00
BALL SCREW
2
24
LF3-M71AR-00
COVER,JOINT
2
25
LF3-M71AS-00
BEARING
2
26
LE6-M7130-00
HOLDER NOZZLE ASSY
1
27
LF3-M7140-00
HOLDER NOZZLE SET
1
28
90112-02J006
BOLT HEX,SOCKET HEAD
8
29
90112-2AJ006
BOLT, HEX.SOCKET HEAD
26
30
90112-2AJ010
BOLT, HEX.SOCKET HEAD
4
31
90115-2AJ010
BOLT, HEX. SOCKET HEAD
8
32
90440-10J023
CIRCLIP
2
33
90933-02J683
BEARING
2
34
90990-01J101
BOLT HEX,SOCKET HEAD
2
35
90990-22J010
PACKING
4
36
91312-03016
BOLT HEX,SOCKET HEAD
2
37
92990-03600
WASHER,PLAIN
4
38
95602-04100
NUT,S/L
2
39
99480-03008
PIN,PARALLEL
1
