SIPLACE Wafer System
Page 45 / 47 23.11.2021
Pos. Item no. Description Part marking
276 03045194-01 DIN EN ISO 7380-M3 X 6-A2-70 STANDARD PARTS
277 00385143-01 BOARD- DCM-INT1 REF.0 SPARE PART
278 03056913-01 ISO 4762 - M 4 X 5-A2-70 STANDARD PARTS
279 03042547-01 ISO 4762 - M 3 X 20-A2-70 STANDARD PARTS
280 03008162-01 ISO 4032 - M3-A2-70 STANDARD PARTS
281 00387493-01 DIFFUSE MODE SENSOR SPARE PART
282 03078186-01 TOP HAT RAIL
00385596-02 MOUNTING RAIL
284 03066505S01 DIFFUSE MODE SENSOR SPARE PART
285 03062594-01 EARTH CONNECTION SCREW M4 (4.
CHOICE)
286 00095472-01 PLAIN WASHER A 4.3-140HV-ST
287 00341997-01 LABEL GROUNDING POINT GNYE
D12.5
288 03009343S01 WARNING LABEL NO. 204 CONSUMABLE
289 03045200-01 DIN EN ISO 7380-M4 X 6-A2-70 STANDARD PARTS
290 03009338-01 WARNING LABEL NO. 201
291 03096025-01 CASING LIFT 2 SWS12 (2,4)
292 03045194-01 DIN EN ISO 7380-M3 X 6-A2-70 STANDARD PARTS
293 03008162-01 ISO 4032 - M3-A2-70 STANDARD PARTS
294 03042507-01 ISO 4762 - M 4 X 16-A2-70 STANDARD PARTS
295 03045200-01 DIN EN ISO 7380-M4 X 6-A2-70 STANDARD PARTS
296 03076833-01 GUIDE RAIL COMPLETE
297 03042553-01 ISO 4762 - M 4 X 12-A2-70 Spare Part
298 03042552-01 ISO 4762 - M 4 X 10-A2-70 STANDARD PARTS
299 03075830-01 SLIDING DOOR COMPLETE
300 03076833-01 GUIDE RAIL COMPLETE
301 03042553-01 ISO 4762 - M 4 X 12-A2-70 Spare Part
302 03042507-01 ISO 4762 - M 4 X 16-A2-70 STANDARD PARTS
303 03096187-01 DRIVE WAFER LIFT COMPLETE
304 03096188-01 DRIVE WAFER LIFT 2
03076606-01 INDUCTIVE SENSOR NBB2-F29-A2
306 00619866-01 PARALLEL PIN 5M5 X 16-ST
307 03076559S01 MOTOR MSSI-055H-030D WITH
PLUG
SPARE PART
308 03023239-01 ISO 7046-2-M3 X 8-A2-70-H STANDARD PARTS
SIPLACE Wafer System
Page 46 / 47 23.11.2021
Pos. Item no. Description Part marking
309 03076311-01 LIFT TABLE
310 00619866-01 PARALLEL PIN 5M5 X 16-ST
311 03076689-01 MICRO SWITCH-KEY SAIA BURGESS
XCG3-S1Z1
SPARE PART
312 03096366-01 TOP HAT RAIL B35XH7,5XL72
00385596-02 MOUNTING RAIL
03096367-02 ELEKTRIC MAGAZINE LIFT
00385158S01 2-AXIS MOTION CONTROLLER
ACCELERA PCI
SPARE PART
00385215-01 END HOLDER
00385162-03 MAIN-SWITCH AND EMERGENCY
317 03078406-01 MAIN SWITCH SPARE PART
318 00334073-01 MUSHROOM PUSHBUTTON 3SB3
RED 40MM
SPARE PART
00385592-01 KEY-SWITCH 3SB34 / 1S
00385591-01 KEY-SWITCH 3SB34 / 1S
321 00386062-01 DISPLAY SUPPORT WITH USB
00385598-01 ELECTRIC DISPLAY SUPPORT
03059594-03 USB-KEYBOARD ACTIVE KEY WITH
TOUCH-PAD
SPARE PART
00385178-01 MONITOR-CAB 3M VGA ST./ST.
15POL/HD
Spare
00385176-01 USB-CABEL 3M USB-A/ST. TO USB-
A/BU.
SPARE PART
03001949S01 KLETTOSTAR-CLING 20X80 STANDARD PARTS
03002842S01 KLETTOSTAR FLEECE 20X80 STANDARD PARTS
00386004-01 CABLE: INTERFACE
RS232-BARCODE
SPARE PART
03099226-01 USB REPEATER CABLE A-PLUG - A-
JACK 5M
SPARE PART
03001949S01 KLETTOSTAR-CLING 20X80 STANDARD PARTS
03002842S01 KLETTOSTAR FLEECE 20X80 STANDARD PARTS
332 03078913-04 MONITOR SCD1520-TDC SPARE PART
00385163-01 ADD-ON KIT DIE-ATTACH-UNIT
00385154S01 8-AXIS POSITION CONTROLLER
ACCELERA PCI
SPARE PART
00386156-01 RIBBON CABLE CONNECT. 100PIN
TO 2X 50PIN
SPARE PART
SIPLACE Wafer System
Page 47 / 47 23.11.2021
Pos. Item no. Description Part marking
336 00385155-01 AMPLIFIER MODULE SPARE PART
00386238-01 CABLE-SET DIE-ATTACH-UNIT
00386234-01 CABLEL: ENCODER ROTOR DIE-
ATTACH-UNIT
SPARE PART
00386235-01 CABLE: ENCODER FLIP-X SPARE PART
00386236-01 CABLEL: MOTOR-CABLEL M7 SPARE PART
00386020-01 CABLE: CONTROL DIE-ATTACH-UNIT SPARE PART
342 00386151-02 ADAPTER CARRIER SWS12 (2,4)
343 03042553-01 ISO 4762 - M 4 X 12-A2-70 Spare Part
344 03042542-01 ISO 4762 - M 3 X 8-A2-70 STANDARD PARTS
345 03073457S01 O-RING 5 X 2 NBR WEAR PART
00388705-02 HALCON DONGLE PACKAGE V10.0 Spare Part
00388758-01 BASIS PACKET HALCON SW-
PRODUKTE
00066212-01 VERPACKUNG F. SOFTWARE CD-
ROM/DISK.
00066122-01 HINGED COVER BOX 314*224*35
00066125-01 PUNCHING INSERT F. DISK
00066211-01 PUNCHING INSERT F. CD-ROM
00322327-01 PUNCHING INSERT COVER
