Page 11
TECHNICAL PUBLICATIONS
Dual Rotary Positioning Assembly - BHS T46230809 Rev.C
This Document Supports Assembly 46230809
Drawing Notes:
Lubricate screws and torque to 90 IN-LB.
Bottom plunger and loosen 1/4 turn.
Apply Loctite 222 - UIC #BLKM07389.
Remove existing screws and replace with Det. 140 (2).
Remove stop block and dowel pins when board widths exceed 10.25 IN.
Used only with board widths up to 10.25 IN. Any board widths larger, remove guides and
use Det. 62 as a board guide. Remove Det. 140 and replace with screws located onbad
board hopper bracket. When not using Details 63 and 67, attach to bad board hopper
bracket.
Limit actuators to be set for 18 X 18 insertion area.
Assemble bearings face to face, see Detail H.
Replace existing set screws with Det. 78 (4).
Remove existing set screw and replace with Det. 34.
Apply Loctite 242 - UIC #BLKM07402.
Fasten with Loctite 495.
Secure Det. 49 (2) using the tapped hole that lies completely on pad.
Set up dimension from the face of the bearing bracket to the face of the pulley hub.
Locate the pulley on the shaft with the set screw, detail 34, then tighten the two #8 cap
head screws to secure the pulley to the shaft.
Orient the extended hub of the bearing to the right when viewing the shaft from the front of
the machine.
Do not wrap cable around encoder body.
With the leadscrew shaft through bearing bore, use 47492401 to torque to 65 ± 5 in-lbs.
Torque to 50 ± 5 in-lbs.
Leave a slight gap (up to 1/16 inch) between the shoulder on detail 1 and the inner face of
detail 44.
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
Page 12
TECHNICAL PUBLICATIONS
T46230809 Rev. C Dual Rotary Positioning Assembly - BHS
This Document Supports Assembly 46230809
Detail No. Item No. Description Qty U/M
1 40922401 BALL SCREW UNIT 2 EA
2 14797006 BELLOW, DUST 2 EA
3 BLKE01630 TIE WRAP 1 EA
4 BLKM06540 NO-MAR SET SCR #10-32 x 15/64 2 EA
5 80000515 SHCS 10-32 x 1/2 8 EA
6 18952002 PADDLE, Y 1 EA
7 80010512 DOWEL 1/2 DIA x 5 1 EA
8 80005005 SSSFP 1/4-20 x 1/2 1 EA
9 46991001 PLATE, RETAINER 1 EA
10 80004805 SSSFP 8-32 X 3/8 4 EA
11 14338000 SHAFT, Y AXIS 2 EA
12 80000521 SHCS 10-32 x 1 1/2 14 EA
13 17702003 BASE 1 EA
14 12837000 GEARBELT 2 EA
15 47082601 SWITCH 4 EA
16 45121802 COUPLING, FLEX 2 EA
17 80019002 ITLW #4 14 EA
18 14346000 SWITCH HOUSING 1 EA
19 80000304 SHCS 6-32 x 5/8 2 EA
20 80018803 FW #6 2 EA
21 80018703 SLW #6 4 EA
22 80010106 DOWEL 1/4 DIA X 1 1/4 2 EA
23
24 80008408 PHMS 4-40 x 5/8 12 EA
25 14331000 COVER, HOUSING 1 EA
26 80000103 SHCS 4-40 x 3/8 8 EA
27 80000519 SHCS 10-32 X 1 5 EA
28 BLKE01298 GROMMET 1 EA
29 14328001 PIN, ACTUATOR 4 EA
30 BLKM06319 RETAINING RING 4 EA
31 20267000 SUPPORT, BRG 1 EA
32 80000604 SHCS 1/4-20 x 5/8 12 EA
33 15102001 PULLEY, GEARBELT 3 EA
34 80005803 SSSCNP 10-24 x 1/2 3 EA
35 46684301 BEARING, BALL 2 EA
36 80001302 SBHS 4-40 x 3/8 6 EA
37 46311302 ACTUATOR ASSEMBLY 1 EA
38 20266000 SHAFT 1 EA
39 15092000 GEARBELT 1 EA
40 46987301 BLOCK, X STOP 1 EA
41 46910201 ROTARY ENCODER ASSY 2 EA
42 17691000 SUPPORT, BRG 1 EA
43 10593001 BEARING, BALL 2 EA
44 17689000 BLOCK, BRG 1 EA
45 80009904 DOWEL 1/8 DIA x 3/4 2 EA
46
47 22260003 VINYL/.25 FOAM 1 EA
48 46278403 ARM, ACTUATOR 2 EA
49 80001602 SBHS 10-24 X 3/8 4 EA
50 80018704 SLW #8 11 EA
51 22260002 VINYL/.25 FOAM 1 EA
52 30587603 BRACKET, LOCKING 4 EA
53 80001501 SBHS 8-32 X 1/4 4 EA
54 46312601 GUIDEWHEEL BEARING ASSY 4 EA
55 46277702 STUD, GUIDE WHEEL 4 EA
56 80018804 FW #8 7 EA
57 17656001 PLATE, MTG. 1 EA
58 80001602 SBHS 10-24 x 3/8 4 EA
59 17700001 COVER, Y FRAME 1 EA
60 80001402 SBHS 6-32 x 3/8 1 EA
Bill of Materials
Page 13
TECHNICAL PUBLICATIONS
Dual Rotary Positioning Assembly - BHS T46230809 Rev.C
This Document Supports Assembly 46230809
61 46247901 GUIDE, PLATE 1 EA
62 46247803 GUIDE, REAR BOARD 1 EA
63 46247406 GUIDE, BOARD 1 EA
64 22243011 VINYL, DAMPING 2 EA
65 22243016 VINYL, DAMPING 1 EA
66 46987201 STOP, X 1 EA
67 46247405 GUIDE, BOARD 1 EA
68 80014904 SPRING PIN 1 EA
69 18333000 COLLAR 4 EA
70 80010102 DOWEL 1/4 DIA x 5/8 12 EA
71 80000712 SHCS 5/16-18 X 2 1/2 1 EA
72 80000707 SHCS 5/16-18 X 1 1/4 1 EA
73 80018806 FW #10 32 EA
74 80018705 SLW #10 42 EA
75 80015103 HEX JAM NUT 5/16-18 2 EA
76 80018706 SLW 1/4 3 EA
77 80001704 SBHS 1/4-20 x 3/4 12 EA
78 80000110 SHCS 4-40 X 5/16 8 EA
79 30395801 STOP, Y 1 EA
80 80015101 HEX JAM NUT 1/4-20 1 EA
81 46194901 STOP, X 1 EA
82 80010506 DOWEL 1/2 DIA X 2 1 EA
83
84 46217002 ROTARY TABLE ASSY 2 EA
85
86 80001011 SHCS 1/2-13 X 2 1/2 6 EA
87 10077004 KEY, WOODRUFF 2 EA
88 80001802 SBHS 5/16-18 X 1/2 2 EA
89 80004704 SOC. SET SCR. FL. PT. 6-32 x 3/8 4 EA
90 80002502 FSHS 8-32 X 1/2 3 EA
91 40200105 C FRAME 1 EA
92 46564801 PULLEY 2 EA
93 30587602 BRACKET, LOCKING 4 EA
94 30780801 SPACER 4 EA
95 80001606 SBHS 10-24 x 7/8 4 EA
96 80000515 SHCS 10-32 x 1/2 2 EA
97 30648002 DRIVE ASSY 2 EA
98 80002612 SFHS 10-32 x 1 4 EA
99 80023508 HEX NUT-MS 10-32 4 EA
100 BLKE01073 CABLE CLAMP, 5/16, BLACK 2 EA
101 80008602 PHMS 8-32 x 1/4 2 EA
102 42372703 X FRAME 2 EA
103 15055000 BUSHING, BALL 8 EA
104 30013000 PLUNGER, SPRING 8 EA
105 18388000 RETAINER 8 EA
106 46194802 BLOCK, SUPPORT 1 EA
107 80000606 SHCS 1/4-20 x 7/8 2 EA
108 14797002 BELLOW, DUST 1 EA
109 80010003 DOWEL 3/16 DIA x 3/4 1 EA
110 80000603 SHCS 1/4-20 x 1/2 11 EA
111 80000407 SHCS 8-32 x 1 5 EA
112 17657000 PLATE, MTG. 1 EA
113 80001610 SBHS 10-32 x 1/2 8 EA
114 42372601 TROLLEY, ROT 2 EA
115 46587901 GEAR BELT 2 EA
116 17615000 CAM 2 EA
117 18058000 LOCK ASSY 2 EA
118 40395901 MECH SLOWDOWN ASSY 1 EA
119 80007601 HHCS 1/4-20 x 1/2 3 EA
Bill of Materials
Detail No. Item No. Description Qty U/M
