-  - 2. COV ER C OM PON ENT S 4 6 8 1 0 1 1 1 2 1 2 1 3 1 6 1 7 2 6 1 9 2 0 3 2 1 3 2 1 2 2 2 3 2 4 2 5 2 5 2 6 1 8 2 6 2 6 2 6 2 6 2 2 2 A A 2 7 2 7 2 8 2 9 2 9 2 9 3 0 3 1 3 2 3 2 3 3 3 3 3 4 3 4 3 5 3 6 3 6 3 7 3 9 …

100%1 / 100
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-55881 SUB_FRAME_ASSY_RV-2 1
2 401-58467 ST AND BZ WIRE ASM (1)
3 401-57149 CABLE BARE (1)
4 401-58599 TIE ANCHOR (23)
5 401-57151 PIN_GAS SPRING HINGE (2)
6 401-57152 BRACKET_BREAKER (1)
7 401-57153 STOPPER (B)_FRONT COVER (2)
8 401-57154 PLATE_SPRING BASE (1)
9 401-57155 REAR UP COVER BRACKET (2)
10 401-57156 Y-CABLE BARE BRACKET (1)
11 401-57157 HERNESS PLATE (1)
12 401-57158 SIGNAL TOWER BASE BRACKET (1)
13 401-57159 SIGNAL TOWER BRACKET (1)
14 401-57160 GUIDE(L) (1)
15 401-57161 GUIDE(R) (1)
16 401-57162 COVER BRACKET(A) (4)
17 401-57163 BREAKER STAND(L) (1)
18 401-57164 BREAKER STAND(R) (1)
19 401-73092 KEY SWITCH BRACKET (1)
20 401-57166 SAFETY SWITCH PLATE NUT (1)
21 401-57167 COMPACT AIR CYLINDER(CUJB20-10S) (1)
22 PJ-3040405-04 ELBOW UNION (1)
23 401-57168 FRONT COVER BRACKET(R) (1)
24 401-57169 FRONT COVER BRACKET(L) (1)
25 401-57170 HERNESS PLATE L (1)
26 401-57171 Y CABLE BARE BRACKET2 (1)
27 401-57172 SIDE BRACKET L (1)
28 401-57173 SIDE BRACKET R (1)
29 401-57174 TOP COVER SUPPORT (1)
30 401-57175 TOP COVER SUPPORT2 (1)
31 401-57176 SUPPORT FRAME (1)
32 401-57177 SIDE BRACKET PLATE (2)
33 401-57178 GUIDE STOP PLATE (2)
34 401-57179 FRONT COVER STOPPER(A) (2)
35 401-57180 FULCRUM PIN(1) (2)
36 HA-0068000-00 CIRCUIT PROTECTOR (1)
37 400-81751 B_COVER_SCREW (2)
38 WP-0430801-SD WASHER M4 (16)
39 WS-0410002-KP SPRING WASHER (4)
40 SM-6040602-TT SCREW M4 L=6 (23)
41 SM-6040802-TT SCREW M4 L=8 (44)
42 SM-6041202-TT SCREW M4 L=12 (4)
43 SM-6041602-TT SCREW M4 L=16 (6)
44 SM-6043002-TT SCREW M4 L=30 (2)
45 SM-6051202-TT SCREW M5 L=12 (20)
46 SM-6051402-TT SCREW M5 L=14 (6)
47 SM-6051602-TT SCREW M5 L=16 (10)
48 SM-6052002-TT SCREW M5 L=20 (2)
49 SM-6061202-TT SCREW M6 L=12 (8)
50 SM-6082502-TT SCREW M8 L=25 (4)
51 SM-1040801-SE SCREW M4X0.7 L=8 (2)
52 SM-3041252-TN SCREW M4 L=12 (8)
53 SM-3061252-TN SCREW M6 L=12 (8)
54 HA-0065400-10 CIRCUIT PROTECTOR (1)
55 HA-0067800-00 SWITCH (1)
56 HX-0050000-00 CONDUIT (1)
57 E9632-715-F00 ZIPPER TUBE (GPJ-50) (0.1)
58 HX-0023300-0A CABLE BAMD (16)
59 401-62080 SPRING BASE PLATE R (1)
60 401-58597 EDGE PROTECT W3.2 (0.15)
61 401-58597 EDGE PROTECT W3.2 (0.15)
62 401-58597 EDGE PROTECT W3.2 (0.1)
63 401-58597 EDGE PROTECT W3.2 (0.03)
64 E9567-319-000 EARTH MARK 8
65 401-62190 ONE SIDE PAN HEAD MACHINE SCREW 2
66 400-70188 CAUTION_LABEL_50 3
67 CM-3002000-06 FINGER INJURY CAUTION LABEL (100) 1
68 CM-3001000-04 DANGER LABEL (50) 5
69 E1326-715-000 EMERGENCY SEAL 1
70 168-70206 GRAVITY SEAL 4
71 CM-3009000-06 WATCH_YOUR_HANDS_LABEL(100) 2
72 CM-6005001-03 CHINA ROHS LABEL 10 L 1
73 E9635-455-000 REVISION SEAL 1
74 CM-5001000-01 CE MARKING LABEL 1
75 400-81030 LABEL HOT SURFACE S 2
76 CM-3002000-04 LABEL (50) 2
77 E9632-715-F00 ZIPPER TUBE (GPJ-50) 0.2
78 E9632-715-E00 ZIPPER TUBE (GPJ-40) 0.2
79 E9632-715-F00 ZIPPER TUBE (GPJ-50) 0.2
80 401-58597 EDGE PROTECT W3.2 0.3
81 401-58597 EDGE PROTECT W3.2 0.25
82 CM-3001000-01 LABEL 1
83 CM-2001000-01 PE MARK LABEL 1
84 HX-0023300-00 CLIP 50
85 HX-0023300-0E NYLON BAND 33
86 HX-0023300-0G CABLE BAND 39
- -
2. COVER COMPONENTS
4
6
8
1 0
1 1
1 2
1 2
1 3
1 6
1 7
2 6
1 9
2 0
3
2 1
3
2 1
2 2
2 3
2 4
2 5
2 5
2 6
1 8
2 6
2 6
2 6
2 6
2
2
2
A
A
2 7
2 7
2 8
2 9
2 9
2 9
3 0
3 1
3 2 3 2
3 3
3 3
3 4
3 4
3 5
3 63 6
3 7
3 9
4 0
4 1
4 2
4 6
7 1
4 7
7 1
4 8
4 9
4 4
5 2
5 3
5 3
5 4
5 5
5 6
5 7
5 8
6 0
7 1
6 1
6 2
6 3
6 3
6 4
6 6
6 5
6 7
6 8
6 9
6 9
7 1
7 1
7 1
7 1
7 1
7 1
7 1
7 1
7 1
7 1
7 1
7 2
7 2
7 2
7 2
7 3
7 3
7 3
7 3
7 4
7 4
7 4
7 4
7 5
7 8
7 9
7 9
7 9
7 9
7 7
7 7
7 6
7 6
8 0
8 1
8 3
8 4
B
7 1
C
C
5 0
5 2
7 5
7 7
5 0
8 2
6 8
6
9
7
2
5
1
3 0
7 1
4 3
8 5
1 5
1 5
1 5
1 5
1 4
2 7
3 8
3 6
3 2
2 7
B
8 7
7 8
5 8
8 7
5 9
7 1
7 6
8 6
7 6
7 0
7 0
5 1
4 5
7 7
8 8
2
1 5
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-57744 SLID-LID_ASY_RV-2 1
2 401-58599 TIE ANCHOR (5)
3 401-57021 SPRING (KPG120-60)_GAS (2)
4 401-57022 OVAL PULLS (A-41-L-30) (1)
5 401-57023 FRONT UP COVER (1)
6 401-57024 FRONT UP COVER STAY (2)
7 401-57025 MONITOR FIXING BRACKET(L) (1)
8 401-57026 MONITOR FIXING BRACKET(R) (1)
9 401-57027 RUBBER FIXING PLATE (1)
10 401-57028 TILT STOPPER RUBBER (1)
11 401-57029 MONITOR RETAINER BRACKET (1)
12 401-57030 STAINLESS HINGE(B-1078-15) (6)
13 401-57031 DISPLAY MOUNTING PARTS (1)
14 401-73091 SAFETY KEY BRACKET (1)
15 SM-6040602-TT SCREW M4 L=6 (5)
16 401-57034 BRAND MARKLABEL(RV-2) (1)
17 401-57035 TOP COVER (1)
18 401-57036 TILT PLATE (1)
19 401-57037 MONITOR SUPPORT PLATE (1)
20 401-57038 CAM FOLLOWER (2)
21 401-57039 FULCRUM PIN(2) (2)
22 401-57040 WASHER (2)
23 401-57041 HANDLE SPACER (2)
24 401-58300 MONITOR (1)
25 400-81751 B_COVER_SCREW (10)
26 SM-6040802-TT SCREW M4 L=8 (12)
27 SM-6041002-TT SCREW M4 L=10 (8)
28 SM-6044002-TT SCREW M4 L=40 (2)
29 SM-6051402-TT SCREW M5 L=14 (6)
30 SM-6061202-TT SCREW M6 L=12 (36)
31 SM-6081202-TP SCREW M8 L=12 (2)
32 WP-0430801-SD WASHER M4 (6)
33 WP-0531001-SC WASHER M5 (4)
34 WS-0510002-KN SPRING WASHER M5 (4)
35 WS-0820002-KN SPRING WASHER M8 (2)
36 WS-0410002-KP SPRING WASHER (6)
37 SL-4040891-SC SCREW M4 L=8 (2)
38 HA-0045500-10 DOOR SWITCH KEY (1)
39 401-58595 EDGE PROTECT W1.6 (0.02)
40 401-58595 EDGE PROTECT W1.6 (0.02)
41 401-58595 EDGE PROTECT W1.6 (0.05)
42 401-58595 EDGE PROTECT W1.6 (0.05)
43 401-58599 TIE ANCHOR 1
44 401-57082 PLATE_USB FIXED 3
45 401-57108 LOW HEAD SCREW (C3X8) 4
46 401-57083 FRONT SIDE UP COVER(L) 1
47 401-57084 FRONT SIDE UP COVER(R) 1
48 401-57085 FRONT SIDE UNDER COVER(L) 1
49 401-57086 FRONT SIDE UNDER COVER(R) 1
50 401-57087 COVER GUIDE BRACKET 2
51 401-57088 ACCESS COVER 1
52 401-57089 MAGNET CATCH(C-166) 2
53 401-57090 LOW HEAD SCREW(CP5X8) 4
54 401-57091 REAR UP COVER 1
55 401-57092 REAR TOP COVER 1
56 401-57093 REAR FUN BRACKET 1
57 401-57094 REAR UNDER COVER 1
58 401-57095 ACCESS COVER FIXING PLATE 2
59 401-57096 FRONT DOWN COVER 1
60 401-57097 ACCESS COVER STAND 1
61 401-57098 SIDE MIDDLE COVER(L) 1
62 401-57099 SIDE MIDDLE COVER(R) 1
63 401-57100 SIDE UNDER COVER 2
64 401-57101 LOW HEAD SCREW(K3X5) 6
65 401-57102 SIDE UP COVER(L) 1
66 401-57103 SIDE UP COVER(R) 1
67 401-57104 AIR MACHINE COVER 1
68 401-57105 COVER STAY 2
69 401-57106 FILTER 2
70 401-57107 ACCESS COVER PLATE NUT 2
71 400-81751 B_COVER_SCREW 86
72 401-33768 DC FAN 4
73 HM-0003300-20 FINGER GUARD 4
74 NM-6040002-SN NUT M4 16
75 SM-6030802-TT SCREW M3 L=8 4
76 SM-6040602-TT SCREW M4 L=6 5
77 SM-6041002-TT SCREW M4 L=10 8
78 SM-6061002-TT SCREW M6 L=10 8
79 SL-4044091-ST SCREW M4 L=40 16
80 HA-0067700-00 SWITCH 1
81 EZ-1846553-11 CABLE EMG 1
82 EZ-1846554-11 CABLE SW 1
83 EZ-1846555-11 CABLE SW 1
84 HX-0023300-00 CLIP 19
85 HM-0010100-1A FAN MOTOR 2
86 401-78089 RV2 DOUSER BRACKET A 1
87 SM-6060802-TT SCREW M6 L=8 4
88 401-78090 RV2 DOUSER BOX 1
