Installation Manual, Station Software Version 704.01 04/2010 Edition
14 of 60
4.1.3 Embedded software
Machine type
Subsystem BIOS / Application File name
X4I X4 X3 X2 SX1/
SX2
SX4
BIOS AXIALL_0040033F.BHX X X X X
Application 1 AXIALL_00410338.BHX X X X X
Gantry axes
A364
Application 2 / X, Y AXIALL_00420686.BHX X X X X
BIOS AXIALL_0070000C.BHX X
Application 1 AXIALL_007100A3.BHX X
Gantry axes
not H-gantry
SX-series
Application 2 / X, Y AXIALL_00720686.BHX X
BIOS AXIALL_0080000C.BHX X
Application 1 AXIALL_008100A3.BHX X
Gantry axes
GCU, H-gantry
SX-series
Application 2 / X, Y AXIALL_00820686.BHX X
BIOS AXIALL_0040033F.BHX X X X
Application 1 AXIALL_00410338.BHX X X X
Z- and DP axis
Twin Head
Application 2 / Z, DP AXIALL_00420686.BHX X X X
BIOS AXIALL_0040033F.BHX X X X X
Application 1 AXIALL_00410338.BHX X X X X
Z- and star axis
C&P20A head
Application 2 / star, Z AXIALL_00420686.BHX X X X X
BIOS VHSAXD_00400104.HEX X X X X
DP axis
C&P20A head
Application 1 VHSAXD_00410307.HEX X X X X
BIOS AXIALL_0060000C.BHX X X
Application 1 AXIALL_006100A3.BHX X X
Z- and star axis
HCU
CPP head
Applikation 2 / star, Z AXIALL_00620686.BHX X X
BIOS CPPAXD_00100124.BHX X X X X X X
Application 1 CPPAXD_0011013F.BHX X X X X X X
DP axis
CPP head
Application 2 CPPAXD_00120115.BHX X X X X X X
BIOS WPCAXI_0040033F.BHX X
Application 1 WPCAXI_00410322.BHX X
WPC5 / WPC6
feed axis
Application 2 WPCAXI_00420496.BHX X
BIOS WPCAXI_0040033F.BHX X
Application 1 WPCAXI_00410322.BHX X
WPC5 / WPC6
lift axis
Application 2 WPCAXI_00420496.BHX X
Installation Manual, Station Software Version 704.01 04/2010 Edition
15 of 60
Machine type
Subsystem BIOS / Application File name
X4I X4 X3 X2 SX1/
SX2
SX4
BIOS TWIHED_001003D2.BHX X X X
Twin Head
2 processors
Application 1 TWIHED_0011020A.BHX X X X
BIOS TWIHED_003003D2.BHX X X X
Twin Head
1 processor
Application 1 TWIHED_00310210.BHX X X X
BIOS VHSHED_001003D2.BHX X X X X
C&P20A head
Application 1 VHSHED_00116609.BHX X X X X
BIOS CPPHED_001003D2.BHX X X X X
CPP head
Application 1 CPPHED_00116609.BHX X X X X
BIOS CPPSZD_0100102.BHX X X X X X X
CPP head
Z-bottom
Application CPPSZD_0110104.BHX X X X X X X
BIOS CPPAVA_00000105.BHX X X X X X X
CPP head
valve cluster
Application CPPAVA_00010129.BHX X X X X X X
BIOS
COMTAB_00500200.BHX
COMTAB_00600007.BHX
X
X
X
X
X
X
X
X
Changeover table
(X-table)
Application 1
COMTAB_00510436.BHX
COMTAB_00610127.BHX
X
X
X
X
X
X
X
X
BIOS COMTAB_00800007.BHX X X
Changeover table
SX-series
Application 1 COMTAB_00810127.BHX X X
BIOS TAPCUT_00300102.BHX X X X X
Tape cutter
X-series
Application 1 TAPCUT_0031010B.BHX X X X X
BIOS CONVEY_00600307.HEX X X X X
PCB conveyor
X-series
Application 1 CONVEY_00610744.HEX X X X X
BIOS CONVEY_00700100.BHX X
PCB conveyor
SX1/SX2
Application 1 CONVEY_00710209.BHX X
BIOS CONVEY_00800100.BHX X
PCB conveyor
SX4
Application 1 CONVEY_00810209.BHX X
BIOS IOMODU_00100340.BHX X X X X
Main distributor/
subdistributor
X-series
Application 1 IOMODU_001103C6.BHX X X X X
BIOS IOMODU_00300002.BHX X
Main distributor/
subdistributor
SX1/SX2
Application 1 IOMODU_00310031.BHX
X
Installation Manual, Station Software Version 704.01 04/2010 Edition
16 of 60
Machine type
Subsystem BIOS / Application File name
X4I X4 X3 X2 SX1/
SX2
SX4
BIOS IOMODU_00400002.BHX X
Main distributor/
subdistributor
SX4
Application 1 IOMODU_00410033.BHX
X
BIOS ILLUMI_005003D2.BHX X X X X
Vision modules
X-series
Application 1 ILLUMI_00510308.BHX X X X X
BIOS ILLUMI_00600401.BHX X X
Vision modules
HCU
Application 1 ILLUMI_00610406.BHX X X
BIOS MTCHNG_00200200.BHX X X X
MTC2
Application 1 MTCHNG_00210301.BHX X X X
BIOS WPCHNG_00500101.BHX X
WPC5
Application 1 WPCHNG_0051020D.BHX X
BIOS WPCHNG_00500101.BHX X
WPC6
Application 1 WPCHNG_0051020D.BHX X
BIOS TWIAPR_00300204.HEX X X X X X
Digital pressure
regulation valve
Twin Head
Application 1 TWIAPR_00310106.HEX X X X X X
BIOS VHSAPR_00300204.HEX X X X X X X
Digital pressure
regulation valve
C&P20A head
Application 1 VHSAPR_0031030B.HEX X X X X X X
BIOS CPPAPR_00300204.HEX X X X X X X
Digital pressure
regulation valve
CPP head
Application 1 CPPAPR_00310505.HEX X X X X X X
BIOS CPPSCO_00100101.HEX X X X X X X
Component sensor
CPP head
Application 1 CPPSCO_00110202.HEX X X X X X X
BIOS FEEDER_A0100102.HEX X X X X X X
X-feeders 8 - 88 mm
Application 1 FEEDER_A0110162.HEX X X X X X X
BIOS FEEDER_B0200101.HEX X X X X X X
X-adapters
Application 1 FEEDER_B0210116.HEX X X X X X X
BIOS FEEDER_C0300100.HEX X X X X X X
X-LDU
*)
Application 1 FEEDER_C0310103.HEX X X X X X X
BIOS FEEDER_D0400100.HEX X X X X X X
X-feeder 2x8 mm
Application 1 FEEDER_D0410101.HEX X X X X X X
*)
can only be downloaded manually by SIPLACE Service
