KJX-1 107 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. P…
KJX-1107
1
31
47
36
45
46
34
41
29
30
17
27
20
3
22
23
4
7
24
25
20
16
23
23
23
12
2
13
15
19
8
12
7
24
44
43
42
35
39
33
32
37
40
28
8
17
17
5
6
21
18
14
24
25
12
17
8
7
12
8
5
26
11
10
9
10
7
10
2
Key Board & Mouse / LCD Stay Assy
Exterior, etc
KJX-1107
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KJX-M1380-00 LCD STAY ASSY. 1 /
38 91312-04006 BOLT HEX.SOCKET HEAD 4
/
2 KHW-M1381-00
BODY,STAND 1
/
39 91312-04012
BOLT HEX.SOCKET HEAD
4
/
3 KHY-M1382-00 BRACKET 1 1 /
40 91312-05014 BOLT HEX.SOCKET HEAD 2
/
4 KHY-M1386-00 BRACKET 2 1 /
41 90990-11J001 SCREW PAN HEAD W/W 5
/
5 KHW-M1383-00 BRACKET 2 2 /
42 KH1-M13A9-00 BUSH 2
6 KKE-M1384-00 BRACKET,LCD 1 /
43 KJX-M13B2-00 BRACKET 2,KEYBOARD 1
7 KHW-M1385-00 SPACER 8 /
44 90990-12J001 SCREW BIN HEAD W/W 4
8 KHW-M1386-00 BUSH 4 /
45 90990-28J118 WASHER PLAIN 2
9 KKE-M138A-00 DAMPER 4 /
46 95302-05600 NUT, HEXAGON 2
10
90990-28J141 WASHER,PLAIN 8 /
47 98702-04006 SCREW, FLAT HEAD 1
11 90990-41J132 COLLAR 4 /
48
12 90990-37J001 WASHER,BELLEVILLE 8 /
49
13 91312-04006 BOLT HEX.SOCKET HEAD 1 /
50
14 91312-04008 BOLT HEX.SOCKET HEAD 4 /
51
15 91312-05010 BOLT HEX.SOCKET HEAD 4 /
52
16 91312-06008 BOLT HEX.SOCKET HEAD 1 /
53
17 91312-06020 BOLT HEX.SOCKET HEAD 4 /
54
18 92902-04200 WASHER PLAIN 4 /
55
19 92902-05200 WASHER PLAIN 4 /
56
20 92902-06600 WASHER PLAIN 2 /
57
21 90172-00J040 WASHER,EXTL.TOOTHED 4 /
58
22 90172-00J050 WASHER,EXTL.TOOTHED 4 /
59
23 95602-06100 NUT,U 4 /
60
24 $NK-2N NYLON CLIP 5 /
61
25 90990-11J001 SCREW PAN HEAD W/W 5 /
62
26 98902-04016 SCREW BINDING HEAD 4 /
63
27 90990-06J001 BOLT,BUTTON HEAD 1 /
64
28 KGA-M13B5-00 MOUSE POCKET ASSY 1 /
65
29
KW3-M5150-60 KEYBOARD E 2 /
66
KW3-M5150-50 KEYBOARD J 2 /
67
30 KW3-M5169-04 MOUSE 2 /
68
31 KJX-M13B3-00 BRACKET,KEYBOARD 1 /
69
32 KGA-M13B2-01 SHAFT,KEYBOARD 1 /
70
33 KGA-M13B3-00 SHAFT,KEYBOARD 2 /
71
34 KGA-M13B4-00 BRACKET,PAD 1 /
72
35 KG2-M1362-00 STOPPER 4 /
73
36 KGB-M1391-00 MOUSE PAD 1 /
74
37 KU1-M9237-50 SPACER 4 /
75
10
2
Key Board & Mouse / LCD Stay Assy
Exterior, etc
KJX-1107
29
12
24
13
33
33
33
6
8
20
24
14
9
23
5
5
4
24
24
31
3
26
18
18
18
30
30
2
2
30
30
19
19
19
26
26
26
17
17
17
17
18
31
36
36
37
27
27
39
39
37
38
34
34
27
27
33
15
21
35
22
32
32
11
10
28
28
28
28
1
28
28
7
20
33
35
35
16
16
25
22
19
11
1
Carrige Assy
Wafer LZ-axis
