Instruction manual SIPLACE TX 3 Technical data and assemblies
From software version 714.0 12/2020 3.1 Performance data
107
3.1.5 PCB conveyor data SIPLACE TX m / TX2i m / TX2i m 4 mm
3
Dual conveyor (standard) Dual conveyor in
"single conveyor"
(optional) mode
Board dimensions (width
*a
x length)
Standard 45 mm x 50 mm to
260 mm x 375 mm
45 mm x 50 mm to
460 mm x 375 mm
Placement accuracy 20 µm (3σ) 45 mm x 50 mm to
260 mm x 375 mm
--
Placement accuracy 15 µm (3σ) 50 mm x 50 mm to
250 mm x 100 mm
--
Stationary conveyor side Outer /outer
Right / right
Left / left
Outside
Automatic electrical width adjustment Standard
PCB thickness
Standard 0.3 mm to 4.5 mm
PCB warpage See page 148
PCB weight
*b
Standard Max. 2.0 kg Max. 2.0 kg
Clearance on PCB underside 33 mm
PCB conveyor height
Option
Standard
Option SMEMA
900 mm
930 mm
950 mm
Type of interface SMEMA or IPC-HERMES-9852
Component-free PCB handling edge 3 mm
PCB changeover time
Dual conveyor 1.3 seconds
*c
0 seconds
*d
*)a When using board widths > 375 mm, make sure that the peripheral modules can also process these board widths.
*)b The board weight value refers to the weight of the board plus the weight of the components.
*)c With the "Convoy Mode" option. Without this option 1.8 seconds.
*)d 0 seconds in asynchronous mode
3 Technical data and assemblies Instruction manual SIPLACE TX
3.2 Ambient conditions and connection values From software version 714.0 12/2020
108
3.1.6 Component supply
3.2 Ambient conditions and connection values
3.2.1 Ambient conditions for packaging, transportation and storage
3
3.2.2 Environmental conditions for operation
3
Component supply Tracks occupied
SIPLACE TX
With C&P20 P2
With CPP
With CPP /TH
With CPP or TwinHead and JTF-ML at location 1
38 feeder modules, each with 8mm X
40 feeder modules, each with 8 mm X
40 feeder modules, each with 8 mm X
28 feeder modules, each with 8 mm X
SIPLACE TX2 / TX2i m / TX2i m 4 mm
With C&P20 M3
With CPP M
38 feeder modules, each with 8mm X
40 feeder modules, each with 8 mm X
Technical data
Tape reel diameter to 330.2 mm (13")
Component trolley changeover time < 1 minute
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
Room temperature
SIPLACE TX
Between 15°C and 35°C
Atmospheric humidity 30% to 75%
(on average not higher than 45%, so that there is no risk of
condensation on the placement machine.)
Ambient pressure > 750 mbar (corresponds to 1700 m above mean sea level)
Instruction manual SIPLACE TX 3 Technical data and assemblies
From software version 714.0 12/2020 3.2 Ambient conditions and connection values
109
3.2.3 Compressed air supply and compressed air specification
3
Compressed air supply
Compressed air pressure val-
ues
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air connection 1/2" hose connection
Compressed air consumption
*a
Placement head configuration Compressed air con-
sumption with vac-
uum pump
*b
Compressed air con-
sumption without vac-
uum pump
*c
SIPLACE TX2i/TX2 C&P20 P2/C&P20 P2
CPP / CPP
CPP / TH
120 Nl/min
No option
No option
No option
260 Nl/min
220 Nl/min
SIPLACE TX2i m / TX2i m and
TX2i m 4mm
C&P20 M3/C&P20 M3
CPP M/CPP M
C&P20 M3/ / CPP M
120 Nl/min
No option
190 Nl/min
No option
260 Nl/min
190 Nl/min
SIPLACE TX1 C&P20 P2
CPP
TH
70 Nl/min
No option
No option
No option
130 Nl/min
130 Nl/min
Compressed air specification according to ISO 8573
Particle size (ISO class 3) 5 µm
Particle density (ISO class 3) 5 mg/m³
Maximum oil content (ISO class 1) Particle density 0.01 mg/m³
Pressure dewpoint (ISO class 4) Dewpoint + 3°
*)a Average consumption values.Under normal atmospheric conditions at 20°C and 1013 hPa.
*)b Vacuum pump only for the SIPLACE SpeedStar.
*)c Optional
Important notes
When setting up a placement machine (TX, SX or X-Series S) next to a SIPLACE TX, observe the correct spacing between them. In these
cases, use suitable conveyor extensions to create room of 0.5m for the operator between the two machines.
To achieve top placement performance, fit the first machine in a SIPLACE TX line with an input conveyor extension and the last placement
machine in the line with an output conveyor extension.
