Power supply S-20/S-23HM/F4/F5/F5HM/S-25HM/HS-50 Conversion Instructions
4.1 Modules to be converted 03/2001 Edition
108
4 Converting the power supply unit on HS-50
placement machines
This section describes how to convert the power supply units on HS-50 placement machines in
order to adapt them to the supply networks in individual countries.
4.1 Modules to be converted
The following table lists those modules that have to be converted in order to adapt them to the
power supply network.
The connections for the station computer, LCD screens, uninterruptible power supply and
changeover tables need not be changed since they are connected to the placement machine’s
own 230 VAC system.
Module Sub-module Ratings
Power supply
00336145-xx
Transformer T1
00345634-xx
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
3 x 230 VAC ± 5%
3 x 204 VAC ± 5%
Inrush current limiter
TG 31033-01
00341831-xx
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
3 x 230 VAC ± 5%
3 x 204 VAC ± 5%
Motor protection trip block
ZM-16-PKZ2
00342495-xx
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
Motor protection trip block
ZM-32-PKZ2, USA option
00342496-xx
3 x 230 VAC ± 5%
3 x 204 VAC ± 5%
Service socket BU1
Socket with earthing contact
15A/115 VAC
00346283-01
1 x 115 VAC (USA)
Main power cable, 4 mm²
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
Main power cable (USA), 6 mm²
00345937-xx
3 x 230 VAC ± 5%
3 x 204 VAC ± 5%
Tab. 4 - 1 Modules to be converted
S-20/S-23HM/F4/F5/F5HM/S-25HM/HS-50 Conversion Instructions Power supply
03/2001 Edition 4 Converting the power supply unit on HS-50 placement machines
109
4.2 Tools and equipment
– Set of DIN 911 Allen keys
– Set of slotted-head screwdrivers
– Multimeter
4.3 Parts
4.3.1 110/204 V conversion kit for SIPLACE HS-50,
article no. 00119085-01
The conversion kit consists of the following parts:
– ZM-32-PKZ2 motor protection trip block Article number 00342496-01
– HS-50 cable: machine power supply (USA), Article number 00345937-01
– Socket with earthing contact 15 A, 125 VAC Article number 00346283-01
– Circuit diagram, 110/208 V conversion kit for SIPLACE HS-50
drawing no. 00119085-010101FD4
– Circuit diagram, 110/208 V conversion kit for SIPLACE HS-50
drawing no. 00119085-010101LD4
– Power supply conversion instructions
for SIPLACE S-20/S-23HM/S-25HM/F
4
/F
5
/F5HM/HS-50 Article number. 00191498-01
03/2001 issue, German and English
for SIPLACE
4.3.2 International (3x400 VAC) conversion kit for SIPLACE HS-50
article no. 00119185-01
The conversion kit consists of the following parts:
– ZM-16-PKZ2 motor protection trip block Article number 00342495-01
– Circuit diagram, conversion kit for SIPLACE HS-50, international
drawing no. 00119185-010101FD4
– Circuit diagram, conversion kit for SIPLACE HS-50, international
drawing no. 00119185-010101LD4
– Power supply conversion instructions
for SIPLACE S-20/S-23HM/S-25HM/F
4
/F
5
/F5HM/HS-50 Article number. 00191498-01
03/2001 issue, German and English
for SIPLACE
Power supply S-20/S-23HM/F4/F5/F5HM/S-25HM/HS-50 Conversion Instructions
4.4 Converting the power supply from 3 x 400 VAC to 3 x 204 V ~ 03/2001 Edition
110
4.4 Converting the power supply from 3 x 400 VAC to 3 x 204 V ~
RISK OF DEATH 4
Å Disconnect the machine correctly as described in section 1, page 71.
Å Disconnect the machine from the main power supply.
Å Take suitable action to ensure that the machine cannot be connected to the power supply
during the conversion work.
Å Put up warning signs to indicate that work is being carried out on the electrical system.
4.4.1 Removing the power supply unit
Fig. 4 - 1 Accessing the power supply unit
