User’s Manual SIPLACE HS-50 5 Single Functions Software Vers ion SR.501.xx E dition 01/99 149 6LQJOH)XQFWLRQV
4 Placement Functions User’s Manual SIPLACE HS-50
4.3 Feeders Software Version SR.501.xx Edition 01/99
148
0HDQLQJRIWKH(QWULHVLQWK H7DEOH IRUWKH/LQHDU)HHGH U
– /RF
Number of the location
– 7UDFN
Number of the track
– 'LY
Number of the feeder division
– 7UD\
This column is irrelevant when setting up the locations of a SIPLACE HS-50.
(Only valid for automatic machines with wafflepack changers)
– &PS1DPH
Name of the component
– 9LEUDWH
If the "<==" symbol is displayed in this column, then this means that the linear feeder on
the corresponding track is currently being vibrated.
9LEUDWH7UDFN:LWK/LQHDU)HHGHU
Å Select the entry in the table for the track with the linear feeder that has been refilled and
that is to be vibrated now.
The selected line is highlighted in light blue in the table. The "Vibrate on" button is active.
Å Click on the 9LEUDWHRQbutton.
The components used to refill the track are vibrated to the front.
The "Vibrate off" button is active.
Å Click on the 9LEUDWHRIIbutton when the vibrating is to be switched off.
Vibration stops.
NOTE
If the user interface is switched to a different view, then vibration will also stop.
r
User’s Manual SIPLACE HS-50 5 Single Functions
Software Version SR.501.xx Edition 01/99
149
6LQJOH)XQFWLRQV
5 Single Functions User’s Manual SIPLACE HS-50
5.1 General comments Software Version SR.501.xx Edition 01/99
150
*HQHUDOFRPPHQWV
Gantry functions and transport functions are known as single functions. They are used to set
up and test the machines and to carry out particular actions following a machine shutdown
caused by an error.
Single functions can be used to control various function modules in a defined manner.
WARNING
Single functions may only be executed by appropriately qualified and trained personnel,
since improper handling can result in personal injury/damage to the machine.
