1 Introduction User Manual HS-50
1.10 Setting up the placement system Software Version 5.01 01/99 Issue
30
7UDQVSRUWFRQILJXUDWLRQDQGWUD QV SRUWDWLRQ
The following components are not installed when the placement system is delivered from the
factory:
– keyboards
– monitors
– fault indicator lamps and
– component tables
Å Install the dismantled components for commissioning.
Å Use a fork-lift truck to transport the placement system:
– minimum fork length 2000 mm if the mounting kit is dismantled.
– minimum fork length 2500 mm if the mounting kit is still fitted.
Å Attach the fork-lift truck only at the indicated points.
4XDOLW\RIWKHIRXQGDWLRQ
Å Ensure that
– you set up the placement system on a firm and non-vibrating foundation.
– the load bearing capacity per unit area of the foundation is greater than 1000 kg/m².
&RPSUHVVHGDLUVXSSO\
– The pressure of the compressed air supply must be 5.5 bar ± 0.5 bar.
– The compressed air must conform to the above specification.
This can be achieved with
– oil-free compressors, e.g. Atlas, Copco type ZR4
– compressed air washer/driers
– micro-filters, series X, e.g. from Zander
3RZHUVXSSO\
– The power socket must be fused with the following fuse ratings:
3 x 16 A for 3 x 400 VAC
3x32A for 3x204VAC
3x16A for 3x460VAC
User Manual HS-50 1 Introduction
Software Version 5.01 01/99 Issue 1.10 Setting up the placement system
31
6HWWLQJXSWKHSODFHPHQWV\VWHP
Å Raise the placement system using the fork-lift truck and adjust the feet until there is a gap
of 830 mm (952.5 mm SMEMA height) between the top edge of the PCB conveyors and
the bottom edge of the feet.
Å Leave a gap of 1 to 3 mm between the PCB conveyors of the placement system.
Å Use a cord pulled tight to ensure that all the placement systems are exactly in line with one
another.
Å Adjust each placement system using a spirit level with an accuracy of 0.02 mm/m.
Å Lock the feet in position.
Å Check the placement system again using the spirit level and correct the settings, if neces-
sary.
CAUTION
Make sure that you remove all the shipping braces from the placement system.
Å Fit any components that were dismantled for dispatch.
Å Connect all the electrical and pneumatic lines.
RISK OF DEATH
The electrical connection work MUST be carried out only by appropriately trained and
certified personnel.
1 Introduction User Manual HS-50
1.11 Overview of the modules - controls Software Version 5.01 01/99 Issue
32
2YHUY LHZRIWKHPRGXOHVFRQWUROV
&RQWUROV
1. Operating panel, left 7. Component counter
2. Main switch 8. LCD screen
3. Key switch 9. Keyboard with trackball
4. Stop button (black) 10.Operating panel, right
5. Start button (white) 11.Emergency stop button
6. Component barcode scanner 12. Indicator lamps
4
5
11
5
11
A
A
10
6
9
8
5
12
8
9
5
5
2
4
3
1
8
9
6
7
5
