11 Station extensions / options User Manual HS -50 11.1 HS-50 nozzle changer S oftware Version 5.01 01/99 I ssue 384 3RVLWLRQGHWHFWLRQ There is a posi tion d etection f iduci al on eve ry maga zine. .H\W…
User Manual HS-50 11 Station extensions / options
Software Version 5.0101/99 Issue 11.1 HS-50 nozzle changer
383
(6) Slot for the parallel pin (7) for centering the magazines
(7) Parallel pin for centering the magazines
(8) Parallel pins for opening and closing the locking plate
(9) Magazines
1RWHVRQRSHUDWLRQ
Å When you fill a magazine with a certain nozzle type for the first time, attach an adhesive label
to identify the type.
PLEASE NOTE
Only ONE
nozzle type must be used in each magazine.
Fill the magazines off the machine and always replace complete magazines.
Å Open the locking plate and place the nozzles in the nozzle garages.
Å Close the locking plate so that the nozzles cannot drop out of the magazines.
CAUTION
Before you fill magazine, make sure that all the nozzles on the revolver head have been re-
turned to their magazines.
Å See the UNIX line computer operating instructions for programming the nozzle changers on
the line computer.
PLEASE NOTE
Å Do not allow components to drop onto the magazines. If they do, they could jam the locking
plate.
Å Do not allow components to drop onto free feeder module locations because they will stick to
the magnetic bar. Production may have to be interrupted if the feeder modules are not placed
on the component table correctly. You should therefore regularly clean the magazines and free
locations.
11 Station extensions / options User Manual HS-50
11.1 HS-50 nozzle changer Software Version 5.01 01/99 Issue
384
3RVLWLRQGHWHFWLRQ
There is a position detection fiducial on every magazine.
.H\WR)LJ
(1) Positioning fiducial
(2) Position of the nozzles in the magazine with respect to the positioning fiducial
Å See section 5 "Vision functions" for the use of fiducials.
12 3
4
5
6
7
8
91011
12
Y
X
1
2
User Manual HS-50 11 Station extensions / options
Software Version 5.0101/99 Issue 11.2 Component barcode
385
&RPSRQHQWEDUFRGH
*HQHUDO
With the HS-50 placement system, a barcode reader can be used to check that the track allocation
is correct and to read component data from component reels. A barcode reader is attached to both
of the operating panels on the placement system.
.H\WR)LJ
(1) Barcode reader
(2) Operating panel, right
(3) Operating panel, left
T PCB transport direction
1
3
2
1
T
