Mounting solutions
IPTE mounting systems are designed to handle odd form components, contactors and pins and can also be
used as integration platforms for other process stages like uid dispense, screw driving, heat staking etc.
The exibility of the equipment provides an automation strategy for components and processes even when
variable batch sizes and dierent components styles need to be placed
• Built for high reliability and retain an excellent price/performance ratio
• Placing a wide variety of odd shaped SMD and conventional components
• Intelligent communication to host platform
Manual Station Turntable
- Manual off-line press fit
- Servo controlled or hydro pneumatic press
- 1 Work position
- Excellent process controll for press fit
- SMED (single minute exchange of tooling)
- Free programmable positions/angles/forces/speed
- Manual load/unload
- (semi) Automatic off-line placement
- SMED (single minute exchange of tooling)
- 2 - 4 Work positions
- Odd-form components and assembly processes
- Free programmable positions/angles/forces/speed
- Turn table with manual load/unload
Mounting solutions
EasyMounter
OFP II
FlexPresser II
HSP II
- Automatic in-line placement with force control
- Automatic gripper exchange device with tool
management and tool recognition
- Up to 6 x 90 mm or 8 x 60 mm feeder slots
- Fits most OFP-equipment
- Odd-form components and assembly processes
- Free programmable positions/angles/forces/speed
- Cartesian axis system with lineair motor
- Automatic in-line placement with high press force
- Automatic gripper exchange device with tool
management and tool recognition
- Up to xxx feeder slots
- For different types of components with press fit pins
- Free programmable positions/angles/forces/speed
- Linear axis
- Automatic in-line placement with high performance
- Up to 2 (L-Size: 3 heads) for contact placement
- Up to xxx feeder slots
- For different types of contacts: solid or flexible press fit
pins, 3D-contacts, THT pins
- Free programmable positions and speed
- Linear axis
- Simple and easy off form pick and place unit
- In-line and off-line capable
- Gantry system for fast and efficient placement
- Up to 18 feeder slots
- Odd-form components and assembly processes
- Intuitive operator interface, easy programming
Marking specification
© Jun-21 IPTE www.ipte.com info@ipte.com
EasyMounter HSP II OFP II
Cycle time per component: 3 sec 0,37 sec 0,8 sec (incl. Clinchen)
Placement angle contact: -90 / 0 / +90° or 0 / 180°
Placement accuracy XY: 50 µm (20 µm repeat.) 50 µm (20 µm repeat.) 50 µm (20 µm repeat.)
Placement force: max. 100 N 800 N 100 N
Feeding: max. 2 per head 9 Feeder slots (90 mm)
Feeder types: Axial, Radial, Tape, Stick, Tray Axial, Radial, Tape, Stick, Tray
Component gripper:
Component weight:
Minimum contact distance on PCB: 2,54 mm (depends on contact)
PCB Dimensions: 300 x 300 mm 350 x 470 mm 400 x 450 mm
Electrical power: 3 x 400 V - 5 kVA - 50/60 Hz 3 x 400 V - 3 kVA - 50/60 Hz 3 x 400 V - 5 kVA - 50/60 Hz
Compressed air: 6 - 20% bar, 40 L, DIN ISO 8573 3.4.5 6 - 20% bar, 40 L, DIN ISO 8573 3.4.5 6 - 20% bar, 40 L, DIN ISO 8573 3.4.5
Color: RAL 7035 ESD Safe RAL 7035 ESD Safe RAL 7035 ESD Safe
Outside dimension (L x D x H): 1.000 x 1.300 x 1.840 mm 1.000 x 2.400 x 2.175 mm 1.605 x 2.400 x 2.055 mm
Standards: CE CE CE
Manual Station Turntable FlexPresser II
Cycle time per component: 6 sec (depends on position and tyoe)
Placement angle contact: 10 / + 370 ° (CNC controlled)
Placement accuracy XY:
Placement force: max. 7000 N
Feeding: max. 6 feeders
Feeder types: Axial, Radial, Tape, Stick, Tray
Component gripper: 45° / 60°
Component weight: Max. 400 mm
Minimum contact distance on PCB: ± 50 µ
PCB Dimensions: 60 x 130 mm 390 x 480 mm
Electrical power:
Compressed air: 6 - 20% bar, DIN ISO 8573 3.4.5 6 - 20% bar, DIN ISO 8573 3.4.5
Color: RAL 7035 ESD Safe RAL 7035 ESD Safe RAL 7035 ESD Safe
Outside dimension (L x D x H): 1.210 x 1.210 x 1.960 mm 1.600 x 2.100 x 2.300 mm
Standards: CE CE CE
