MODEL TCM-X300 021 1-001 292 ࠤࡉ࡞㈩✢ CABLE WIRING Fig. SB-2 F1,2 ޔ F3,4 ၮ᧼ޔ XY ၮ᧼ F1,2,F3,4 P .C.B., XY P .C.B. Fig.SB-2 TCM-X300 188 190 189 191 168 171 See Fig.RL-5 Key No.455 F1,2 PCB 179 172 179 173 See Fig.RL-5 Key N…
MODEL TCM-X300
0211-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
291
SB-1
51 630 086 8722 CORD 1 XCN7- 784SB-010-051
52 630 087 0022 CORD (CRT 15P-15P ST2M) 1 XCN5- 784SB-010-052
53 630 087 0046 CORD (RS232C 9P-9P ST2M) 1 XCN1- 784SB-010-053
54 630 088 7877 CORD (SCJI 1.5M) 1 XCN3- 784SB-010-054
55 630 085 3414 CORD 1 XCN28/29- 784SB-010-055
56 630 097 0654 CORD(F-CAM) 1 XCN31- 784SB-010-056
57 630 097 0661 CORD(SIO) 1 XCN26- 784SB-010-057
58 630 111 4859 CORD(MON1.5M) 1 XCN32- 784SB-010-058
59 630 092 9874 CORD(LIGHT) 3 CN1-,CN2-,CN3-, 784SB-010-059
60 630 106 4390 CORD (REC-PIO 2M) 1 XCN25- 784SB-010-060
66 630 109 3413 ASSY,CORD (X200SB105) 1 XCN35-XCN80 784SB-010-066
67 630 108 1861 CORD 1 784SB-010-067
MODEL TCM-X300
0211-001
292
ࠤࡉ࡞㈩✢ CABLE WIRING
Fig. SB-2
F1,2ޔF3,4 ၮ᧼ޔXY ၮ᧼
F1,2,F3,4 P.C.B., XY P.C.B.
Fig.SB-2
TCM-X300
188
190
189
191
168
171
See Fig.RL-5
Key No.455
F1,2 PCB
179
172
179
173
See Fig.RL-5
Key No.455
F3,4 PCB
See Fig.RM-4
Key No.353
193
187
194
190
188
184
186
187
187
187
184
190
192
188
XY PCB
See Fig.RL-5
Key No.467
UB01
178
180
170
177
183
182
197
See Fig.RM-4
Key No.359
UB01
See Fig.RL-5
Key No.467
UB01
154
156
160
159
162
166
169
157
151
152
170
167
MODEL TCM-X300
0211-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
293
SB-2
151 630 109 4434 ASSY,CORD (BPH 3.5M) 1 -BPH21 784SB-010-151
152 630 109 4434 ASSY,CORD (BPH 3.5M) 1 -BPH26 784SB-010-152
154 630 109 4465 ASSY,CORD (BPH 2.5M) 1 -BPH20 784SB-010-154
156 630 109 4489 ASSY,CORD (BPH 1.5M) 1 -BPH22 784SB-010-156
157 630 109 4403 ASSY,CORD (BPH 4.5M) 1 -BPH23 784SB-010-157
159 630 109 4472 ASSY,CORD (BPH 2.0M) 1 -BPH24 784SB-010-159
160 630 109 4373 ASSY,CORD (BPH 6.0M) 1 -BPH25 784SB-010-160
162 630 109 4373 ASSY,CORD (BPH 6.0M) 1 -BPH27 784SB-010-162
166 630 112 1000 ASSY,CORD (3.5M) 1 -SQ04(YSOL05),SPB31(LED31)
784SB-010-166
167 630 112 1000 ASSY,CORD (3.5M) 1 -SQ05(YSOL06),SPB32(LED32)
784SB-010-167
168 630 092 3858 ASSY,CORD (X200SB309) 1 XCN17,18(F1,2)- 784SB-010-168
169 630 112 1000 ASSY,CORD (3.5M) 1 -SQ012(YSOL10),SPB33(LED33)
784SB-010-169
170 630 112 0980 ASSY,CORD(X301SB302) 2 784SB-010-170
171 630 092 3919 ASSY,CORD(X200SB313) 1 XCN34(F1,2)- 784SB-010-171
172 630 092 3926 ASSY,CORD(X200SB314) 1 XCN05,06(F3,4)- 784SB-010-172
173 630 109 4342 ASSY,CORD (2.0M) 1 XCN07(F3,4)- 784SB-010-173
177 630 112 1017 ASSY,CORD (2.5M) 1 -SQ06(YSOL07),SPB35(LED35)
784SB-010-177
178 630 112 0997 ASSY,CORD (4.0M) 1 -SQ07(YSOL08),SPB36(LED36)
784SB-010-178
179 630 092 3902 ASSY,CORD(X200SB312) 1 XCN12,13,14(F3,4)- 784SB-010-179
180 630 112 1017 ASSY,CORD (2.5M) 1 -SQ13(YSOL11),SPB34(LED34)
784SB-010-180
182 630 109 4458 ASSY,CORD (BPH 3.0M) 1 -BPH42 784SB-010-182
183 630 112 1024 ASSY,CORD(BPH 2.0M) 1 -BPH41,43 784SB-010-183
184 630 092 3483 ASSY,CORD(200SB201) 1 XCN09,10,17,18(XY)- 784SB-010-184
186 630 112 1048 ASSY,CORD(2.5M) 1 XCN27(XY)- 784SB-010-186
187 630 112 1055 ASSY,CORD(X301SB204) 1 XCN19,20,21,22,23,24,52,53,26(XY)-
784SB-010-187
188 630 092 3520 ASSY,CORD(X200SB205) 1 XCN11,33(XY)-(XNC71,73-F)
784SB-010-188
189 630 091 3637 ASSY,CORD (X200F11) 1 (XNC71-F)- 784SB-010-189
190 630 092 3537 ASSY,CORD(X200SB206) 1 XCN12,13,14(XY)-(XNC72-F)
784SB-010-190
191 630 091 3620 ASSY,CORD (X200F10) 1 (XNC72-F)- 784SB-010-191
192 630 092 3544 ASSY,CORD(X200SB207) 1 XCN34(XY)- 784SB-010-192
193 630 092 3551 ASSY,CORD(X200SB208) 1 XCN41,40,39,38(XY)- 784SB-010-193
194 630 112 1062 ASSY,CORD(3.5M) 1 XCN50,49,48,46(XY)- 784SB-010-194
197 630 112 1031 ASSY,CORD(2.5M) 1 -(NCN46-J) 784SB-010-197
