Samsung Component Plac er SM321 Service Manu al 4.1.2. Head Ass’y - B NO. P ART NO. P ART NAME Q’TY TYPE R EMARK 1 J71550538B OUTER ILL BRACKET 1 J71550538B 2 J7155539A TER ILL SIDE BRACKET 1 J7155539A OU 3 J7155540A…
Head Module
NO. PART NO. PART NAME Q’TY TYPE REMARK
33 J6602077A TIMING BELT 3 236-2GT-4
34 J7155521B PULLEY (R-AXIS 2) 3 J7155521B
35 J7055655A THETA MOTOR PLATE 1 J7055655A
36 J7255083A THETA MOTOR ISOLATOR 3 J7255083A
37-A J9083190A R12_MOTOR_CABLE_ASSY 3 SM21-MD038
37-B J90831009A R34_MOTOR_CABLE_ASSY 3 SM21-MD039
37-C J90831010A R56_MOTOR_CABLE_ASSY 3 SM21-MD040
38 J9083184A R HOME SENSOR CABLE ASSY 1 SM21-HD013
39 J7055663A SENSOR BRACKET R-M 1 J7055551A
40 J9080829A SWING MOTOR CABLE ASS’Y SM_MD032
41 J7255081A MIRROR MOTOR ISOLATOR 1 J7255081A
42 J7155524A MIRROR MOTOR BRACKET 1 J7155524A
43 J7155523A PULLEY (S-AXIS 2) 1 J7155523A
44 J6602078A TIMING BELT 1 255-3GT-6
45 J7155516A FIDUCIAL CAMERA BRACKET 1 J7155516A
46 J7155517A FIDUCIAL CAMERA CLAMP 1 J7155517A
47 J7155572A CAMERA CABLE HOLDER 1 J7155542A
48 J6751014A CCD CAMERA 1 XC-ES50
49 J90591004A F-MOVING 12058 LENS ASS’Y 1 J9059140A
50 J9060357B HEAD OUTER LED BOARD ASSY 1 REV 1.1
51 J9055357A PULLEY ASSY(Z-AXIS 2) 1 J9055357A
4-3
Samsung Component Placer SM321 Service Manual
4.1.2. Head Ass’y - B
NO. PART NO. PART NAME Q’TY TYPE REMARK
1 J71550538B OUTER ILL BRACKET 1 J71550538B
2 J7155539A TER ILL SIDE BRACKET 1 J7155539A OU
3 J7155540A OUTER ILL SIDE BRACKET 1 1 J7155540A
4 J9060357B HEAD OUTER LED BOARD ASSY 1 Rev 1.1
SPRING 2 AWY 6-50
E-RING 2 DIA1.5(SUS)
SPRING BUSH
5 J6107044A
6 J6071150050
7 J7455026A 4 J7455026A
8 J7055559A 9A MIRROR PIN 2 2 J705555
9 J7055560A MIRROR SPRING BRACKET 2 J7055560A
10 J7055558A MIRROR PIN 1 2 J7055558A
11 J7155526A MIRROR ARM-LEFT 1 J7155526A
12 J6025300036 HEX NUT
FOLLOWER
2 M3
13 J6601081A CAM 2 CF3UU-A
14 J7055143B CAM 2 J7055143B
15 J7155522A PULLEY (S-AXIS 1) 1 J7155522A
16 J7055557A BEARING HOUSING 1 J7055557A
17 J6601079A BALL BEARING 4 695ZZ
18 J7055207B MIRROR SHAFT 1 J7055207B
19 J7055557A BEARING HOUSING 1 J7055163A
20 J7155525A MIRROR SENSOR DOG 1 J7155525A
21 J7155527A MIRROR ARM-RIGHT 1 J7155527A
4-4
Head Module
NO. PART NO. PART NAME Q’TY TYPE REMARK
22 1 J7055151A J7055151A ARM JOINT
BALL23 J6601080A BEARING 4 MR148ZZ
24 GHT 1 J7055155A J7055155A MIRROR JOINT-RI
25 REW 2 J7055153A J7055153A MIRROR SC
26 J7055205A MIRROR JOINT-LEFT 1 J7055205A
27 J7055204A ARM JOINT 1 J7055204A
28 1 J7055556B
J7055556B MIRROR SENSOR BRACKET
29 J3212027A MICRO PHOTO SENSOR 3 PM-L24
30 J7155530A MIRROR SUPPORT 1 J7155530A
31 J6755002A 1 J6755002A
FOLDING MIRROR
32 J7155197A MIRROR FIX PLATE 2 J7155197A
33 J7155515A LOWER COVER 2 1 J7155515A
34 J71550570B SIDE ILLUM BODY 1 J71550570B
35 J9060404A HEAD SIDE LED BOARD ASS’Y 1 Rev 1.0
36 J90551011A SIDE ILLUM GUIDE ASS’Y 2 J90551001A
37 J9083179A SIDE ILL U/D SENSOR CABLE ASS’Y 1 SM-HD006
37-A J6711132A FITTING 1 M-5HL-4
37-B J6711156A HOSE NIPPLE (D/C) 1 M-5H-4
38 J7255085A SIDE ILLUM ISOLATOR 1 J7255085A
39 J7255084A SIDE REFLECTOR 6 J7255084A
4-5
