EDM V2.2 / Installation Manual 10/2013 Edition
5
1 Introduction
This installation manual provides instructions on installing the SIPLACE® EDM software and
configuring the software basically after installation.
It also contains information on the scope of delivery and requirements for successful installation.
1.1 Scope of Delivery
● SIPLACE EDM Basic License V2.x, item no.: [00116662-01] contains:
1 SIPLACE EDM Server License
● SIPLACE EDM Media Package V2.2, item no.: [00116660-01] contains:
Software CD-ROM SIPLACE EDM 2.2
DVD SIPLACE NET Support Media V1.15, item no.: [00392170-01]
Software Installation Manual SIPLACE EDM, (English) item no.: [00197457-01]
The supplied CD-ROM contains the following software components:
● SIPLACE EDM Master Server
● SIPLACE EDM Configuration Manager
● SIPLACE EDM Clearing Pool
● SIPLACE EDM Line Server
● SIPLACE EDM Client
● SIPLACE EDM Data Transfer Manager
● SIPLACE EDM Tool
1.2 Languages
The standard package contains German, English and Chinese (Simplified) versions. Only German
and English are supported for installing EDM.
1.3 Licenses
The following licenses are required for the EDM system:
– EDM Server (Factory)
– EDM Client (Floating), 1x per line server
The Factory license type is valid for the entire production run and is not assigned to a license
server.
The Floating license type is fetched from a license server by the application and then released
again when the application is terminated. However, the number of licenses on the license server is
limited.
EDM V2.2 / Installation Manual 10/2013 Edition
6
2 Prerequisites
– SIPLACE Pro Version 11.1
– SIPLACE OIB Version 3.2 (for displaying Comment dialogs at the station)
The necessary system requirements for SIPLACE EDM correspond basically to the system
requirements for SIPLACE Pro and are described in the SIPLACE Pro Version Description,
item no. [00197400-xx].
NOTICE
System requirements
The Support Media DVD included in the installation package checks the necessary
system requirements of your system and installs these. Amongst others e.g. Microsoft
.NET Framework, the License Manager and the Error Reporting tool.
The use of the Support Media V1.15 is obligatory.
The system requirements (supported operating systems and database variants) and an
overview of the interoperable products can be found in the SIPLACE Support Media
Installation Manual, item no. [00197214-xx].
2.1 Deployment in Combination with OIB
As of version 2.2, EDM requires OIB to display Comment dialogs at the station. For this, the OIB
Display Service has to be installed and configured according to the OIB Display Service installation
instructions. The OIB Display Service Viewer has to be installed and running on each station that
shall display an EDM Comment dialog.
EDM comes with the current version of the required OIB dll files. If OIB is updated to a newer
version, the OIB Client API has to be installed if EDM is installed there, too. The EDM Tool will
check the OIB requirements on startup and display a warning if the EDM functionality might be
limited. EDM tries to register the EDM Data Transfer (Push) API Web Service with the OIB Service
Locator. The API will be available even if this fails. In this case, the EDM Push API Clients will have
to connect to the service directly. EDM still works if OIB is not installed.
