Multilayer Ceramic Capacitor
- 2 -
■
STRUCTURE
Multilayer Ceramic Capacitor
- 3 -
■
APPEARANCE AND DIMENSION
L
BW
T
W
CODE EIA CODE
DIMENSION ( mm )
L W T(MAX) BW
03
0201
0.6
±
0.03 0.3
±
0.03 0.3
±
0.03 0.15
±
0.05
05
0402
1.0
±
0.05 0.5
±
0.05 0.5
±
0.05 0.2+0.15/-0.1
10
0603
1.6
±
0.1 0.8
±
0.1 0.8
±
0.1 0.3
±
0.2
21
0805
2.0
±
0.1 1.25
±
0.1 1.25
±
0.1 0.5+0.2/-0.3
31
1206
3.2
±
0.2 1.6
±
0.2 1.6
±
0.2 0.5+0.2/-0.3
32
1210
3.2
±
0.3 2.5
±
0.2 2.5
±
0.2 0.6
±
0.3
43
1812
4.5
±
0.4 3.2
±
0.3 3.2
±
0.3 0.8
±
0.3
55
2220
5.7
±
0.4 5.0
±
0.4 3.2
±
0.3 1.0
±
0.3
Multilayer Ceramic Capacitor
- 4 -
■
PART NUMBERING
Symbol EIA Code
Temperature
Coefficient(PPM/
℃
)
※
Temperature
Characteristics
Operation
Temperature Range
C
C0G 0
±
30 C
Δ
-55 ~ +125
℃
P
PH -150
±
60 P
Δ
R
RH -220
±
60 R
Δ
S
SH -330
±
60 S
Δ
T
TH -470
±
60 T
Δ
U
UJ -750
±
120 U
Δ
L
SL +350 ~ -1000 SL
▶
CLASS
Ⅰ
(Temperature Compensation)
Temperature
Characteristics
below 2.0pF 2.2 ~ 3.9pF above 4.0pF above 10pF
C
Δ
C0G
C0G C0G C0G
P
Δ
- PJ PH PH
R
Δ
- RJ RH RH
S
Δ
- SJ SH SH
T
Δ
- TJ TH TH
U
Δ
- UJ UJ UJ
Symbol EIA Code
Capacitance Change
(
Δ
C:%)
Operation
Temperature Range
A
X5R
±
15
-55 ~ +85
℃
B
X7R
±
15
-55 ~ +125
℃
F
Y5V
+22 ~ -82 -30 ~ +85
℃
▶
CLASS
Ⅱ
(High Dielectric Constant)
SAMSUNG Multilayer Ceramic Chip Capacitor
Type(Size)
Capacitance Temperature Characteristics
Nominal Capacitance
Capacitance Tolerance
Rated Voltage
Thickness Option
Packaging Type
CL10C101JBNC
CAPACITANCE TEMPERATURE CHARACTERISTICS
※
Temperature Characteristics
☞
J:
±
120 PPM/
℃
H:
±
60 PPM/
℃
G:
±
30 PPM/
℃
●
3
●
7
●
8
●
2
●
6
●
3
●
4
●
5
●
2
●
6
●
3
●
4
●
5
●
7
●
8
●
1
●
1
