PREVENTIVE MAINTENANCE CLEANING, LUBRICATION AND MAINTENANCE D IAGRAMS 35.50 Technical Reference Manu al Chapter Issue 3 Jan 08 Figure 35-2 Dual Lane Figure 35-3 Paste Dispenser S plash Guard S plash Guard Front Print Ma…
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 3 Jan 08 Technical Reference Manual 35.49
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Figure 35-1 Rising Table
A
Tooling (clean)
Manual Tooling Plate (clean)
View on Rear of Rising Table
Transport Rail Drive Belt
Rising Table Drive Belt
Rising Table Ballscrew
Transport Rail Ballscrew
(in 2 positions)
Rising Table Motor
Linear Bearing Block
(in 4 positions)
View on Arrow A
Sensor Vane
Vertical Linear Bearing Guide Rails
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
35.50 Technical Reference Manual Chapter Issue 3 Jan 08
Figure 35-2 Dual Lane
Figure 35-3 Paste Dispenser
Splash Guard
Splash Guard
Front Print Machine Rear Print Machine
View on Rear of Print Carriage
Linear Bearing Guides
Paste Drip Tray
Home Sensor
Home Vane
Paste Dispenser Drive Belt
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 3 Jan 08 Technical Reference Manual 35.51
Figure 35-4 Board Opto Locations
Opto Sensor
Area to be cleaned
Board at Right
Diffuse Opto
Board at Left
Diffuse Opto
NOTE
Board at Left and Board at Right Optos look up.
Board at Stop Opto looks down.
Plan View on Machine
Camera Board Stop
Board at Stop
Diffuse Opto
